40
SECTION 7
ELECTRICAL PARTS LIST
HCD-DX10/RG4SR/RG20/RG30T
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
• Abbreviation
CND : Canadian model
AUS : Australian model
AR : Argentina model
SP : Singapore model
TW : Taiwan model
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
MX : Mexican model
MY : Malaysia model
E2 : 120V AC Area in E model
E3 : 240V AC Area in E model
E51 : Chilean and Peruvian model
ADDRESS SENSOR CD
1-675-911-14 ADDRESS SENSOR BOARD
**********************
< CAPACITOR >
C712 1-164-159-11 CERAMIC 0.1uF 50V
< IC >
IC711 8-749-014-38 PHOTO INTERRUPTER SG-264
IC711 8-749-016-76 IC RPI-321
< RESISTOR >
R711 1-247-876-11 CARBON 75K 5% 1/4W
R712 1-249-409-11 CARBON 220 5% 1/4W F
R713 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S711 1-771-821-11 SWITCH, PUSH (1 KEY)(UP DOWN SW)
************************************************************
A-4726-517-A CD BOARD, COMPLETE
(DX10/RG4SR/RG20:US, CND/RG30T)
******************
A-4726-775-A CD BOARD, COMPLETE (RG20:AEP, UK)
******************
< CAPACITOR >
C704 1-164-159-11 CERAMIC 0.1uF 50V
C705 1-126-947-11 ELECT 47uF 20% 10V
C706 1-164-159-21 CERAMIC 0.1uF 50V
C707 1-126-964-11 ELECT 10uF 20% 50V
C708 1-161-494-00 CERAMIC 0.022uF 25V
C709 1-104-665-11 ELECT 100uF 20% 10V
C710 1-104-665-11 ELECT 100uF 20% 10V
C711 1-162-306-11 CERAMIC 0.01uF 20% 16V
C712 1-126-960-11 ELECT 1uF 20% 50V
C713 1-136-171-00 FILM 0.33uF 5% 50V
C714 1-126-947-11 ELECT 47uF 20% 10V
C715 1-162-294-31 CERAMIC 0.001uF 10% 50V
C716 1-126-947-11 ELECT 47uF 20% 10V
C717 1-126-964-11 ELECT 10uF 20% 50V
C718 1-161-494-00 CERAMIC 0.022uF 25V
C719 1-161-494-00 CERAMIC 0.022uF 25V
C720 1-104-665-11 ELECT 100uF 20% 10V
C723 1-126-957-11 ELECT 0.22uF 20% 50V
C724 1-130-489-00 MYLAR 0.033uF 5% 50V
C725 1-162-288-31 CERAMIC 330PF 10% 50V
C726 1-136-171-00 FILM 0.33uF 5% 50V
C727 1-136-167-00 FILM 0.15uF 5% 50V
C728 1-127-869-11 CERAMIC 2700PF 10% 50V
C730 1-130-485-00 MYLAR 0.015uF 5% 50V
C731 1-130-486-00 MYLAR 0.018uF 10% 50V
C732 1-130-493-00 MYLAR 0.068uF 5% 50V
C734 1-164-159-11 CERAMIC 0.1uF 50V
C735 1-162-286-31 CERAMIC 220PF 10% 50V
C736 1-136-171-00 FILM 0.33uF 5% 50V
C737 1-162-306-11 CERAMIC 0.01uF 20% 16V
C738 1-162-292-31 CERAMIC 680PF 10% 50V
C739 1-162-600-11 CERAMIC 0.0047uF 10% 16V
C740 1-162-286-31 CERAMIC 220PF 10% 50V
C741 1-126-959-11 ELECT 0.47uF 20% 50V
C742 1-126-947-11 ELECT 47uF 20% 10V
C743 1-126-960-11 ELECT 1uF 20% 50V
C744 1-127-870-31 CERAMIC 3300PF 10% 50V
C745 1-162-191-31 CERAMIC 2.2PF 10% 50V
C746 1-162-306-11 CERAMIC 0.01uF 20% 16V
C747 1-164-159-11 CERAMIC 0.1uF 50V
C748 1-162-294-31 CERAMIC 0.001uF 10% 50V
C749 1-162-203-31 CERAMIC 15PF 5% 50V
C750 1-126-963-11 ELECT 4.7uF 20% 50V
C751 1-164-159-11 CERAMIC 0.1uF 50V
C752 1-164-159-11 CERAMIC 0.1uF 50V
C753 1-164-159-11 CERAMIC 0.1uF 50V
C754 1-162-286-31 CERAMIC 220PF 10% 50V
C755 1-161-494-00 CERAMIC 0.022uF 25V
C756 1-126-947-11 ELECT 47uF 20% 10V
C757 1-161-494-00 CERAMIC 0.022uF 25V
C758 1-126-947-11 ELECT 47uF 20% 10V
C759 1-164-159-11 CERAMIC 0.1uF 50V
C760 1-162-284-31 CERAMIC 150PF 10% 50V
C761 1-162-206-31 CERAMIC 20PF 5% 50V
C762 1-162-206-31 CERAMIC 20PF 5% 50V
C763 1-126-947-11 ELECT 47uF 20% 10V
C764 1-161-494-00 CERAMIC 0.022uF 25V
C765 1-161-494-00 CERAMIC 0.022uF 25V
C766 1-161-494-00 CERAMIC 0.022uF 25V
C767 1-162-282-31 CERAMIC 100PF 10% 50V
To Next Page
