Sony HCD-DX255 - Mechanism Deck and Base Unit Removal

17
HCD-DX155/DX255
3-9. DVD MECHANISM DECK (CDM81C-DVBU101)
4 MD COVER
3 four screws (+BV 3)
2 Remove the harness and flexible cable.
flexible cable
harness
1 wire (flat type) 21core (CN508)
5 four screws
(+BVTP 3
× 10)
6 DVD mechanism deck
(CDM81C-DVBU101)
