HCD-DX155/DX255
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
✩ A-1151-985-A MAIN BOARD, COMPLETE (DX155: US, CND)
✩ A-1152-007-A MAIN BOARD, COMPLETE (DX155: SP)
✩ A-1152-028-A MAIN BOARD, COMPLETE (DX255)
✩ A-1171-566-A MAIN BOARD, COMPLETE (DX155: E3)
✩ A-1172-050-A MAIN BOARD, COMPLETE (DX155: AUS)
✩ A-1172-052-A MAIN BOARD, COMPLETE (DX155: MX)
*********************
< CAPACITOR >
C501 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C503 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C504 1-126-947-11 ELECT 47uF 20% 16V
C505 1-126-947-11 ELECT 47uF 20% 16V
C506 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C507 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C508 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C509 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C510 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C511 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C512 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C513 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C514 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C515 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C516 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C517 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C525 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C570 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C571 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C572 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C580 1-104-656-11 ELECT 2200uF 20% 6.3V
C582 1-104-658-91 ELECT 100uF 20% 10V
C583 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C587 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C589 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C594 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C598 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C601 1-126-947-11 ELECT 47uF 20% 16V
C602 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C603 1-104-658-91 ELECT 100uF 20% 10V
C606 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C712 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C716 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C762 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C798 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C799 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C855 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C856 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C875 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1101 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1102 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C1105 1-126-947-11 ELECT 47uF 20% 16V
C1106 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1109 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1110 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1112 1-126-947-11 ELECT 47uF 20% 16V
C1113 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1114 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1115 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1116 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1117 1-126-964-11 ELECT 10uF 20% 50V
C1118 1-126-964-11 ELECT 10uF 20% 50V
C1119 1-126-964-11 ELECT 10uF 20% 50V
C1120 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C1121 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C1122 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C1123 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C1124 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C1125 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1126 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1127 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1128 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C1130 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1131 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C1132 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1133 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1135 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C1136 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1137 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1138 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1139 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C1140 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1144 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1146 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1147 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C1148 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C1149 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1150 1-126-964-11 ELECT 10uF 20% 50V
C1151 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C1152 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C1153 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C1154 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1155 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1156 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1158 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1159 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1160 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1161 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1162 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1163 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1164 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1167 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1170 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1171 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1172 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1173 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1174 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1175 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1176 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1177 1-126-947-11 ELECT 47uF 20% 16V
C1178 1-126-947-11 ELECT 47uF 20% 16V
C1179 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1180 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1181 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1182 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C1184 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1186 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
✩ New part of EEP ROM (IC1103) on the MAIN board cannot be used.
Therefore, if the mounted MAIN board (A-1151-985-A, etc.) is replaced,
exchange new EEP ROM (IC1103) with that used before the replacement.
MAIN
Ver. 1.2
