89
HCD-DX155/DX255
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-4750-232-A RELAY BOARD, COMPLETE
**********************
< CAPACITOR >
C701 1-126-786-11 ELECT 47uF 20% 16V
C702 1-126-791-11 ELECT 10uF 20% 16V
C761 1-162-306-11 CERAMIC 0.01uF 30% 16V
C762 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
CN701 1-779-558-11 CONNECTOR, FFC (LIF (NON-ZIF)) 21P
< DIODE >
D701 8-719-921-40 DIODE MTZJ-T-77-4.7B
D711 8-719-982-10 DIODE MTZJ-T-77-4.3A
< IC >
IC701 8-759-598-69 IC BA6956AN
IC711 8-759-598-69 IC BA6956AN
< TRANSISTOR >
Q751 8-729-119-78 TRANSISTOR 2SC1740S-QRT
< RESISTOR >
R701 1-249-415-11 CARBON 680 5% 1/4W
R702 1-247-807-31 CARBON 100 5% 1/4W
R711 1-249-415-11 CARBON 680 5% 1/4W
R712 1-247-807-31 CARBON 100 5% 1/4W
R751 1-247-806-11 CARBON 91 5% 1/4W
R752 1-249-429-11 CARBON 10K 5% 1/4W
R753 1-249-429-11 CARBON 10K 5% 1/4W
R754 1-249-430-11 CARBON 12K 5% 1/4W
R755 1-249-429-11 CARBON 10K 5% 1/4W
*************************************************************
SENSOR BOARD
*************
< IC >
IC751 8-759-989-76 IC RPR-359F
*************************************************************
SPEAKER BOARD
**************
< CAPACITOR >
C301 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C302 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C303 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C304 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C305 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C306 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C307 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C308 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C309 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C310 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C311 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C312 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C313 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C314 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C315 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C316 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C317 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C318 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C319 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C320 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C321 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C322 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C323 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C324 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
< CONNECTOR >
CN301 1-564-507-11 PLUG, CONNECTOR 4P
CN302 1-564-320-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CN303 1-564-509-11 PLUG, CONNECTOR 6P
< GROUND TERMINAL BOARD >
EP301 1-537-770-21 TERMINAL BOARD, GROUND
EP302 1-537-770-21 TERMINAL BOARD, GROUND
< TERMINAL >
TB301 1-780-344-11 TERMINAL BOARD (SPEAKER) 4P
TB302 1-780-343-11 TERMINAL BOARD (SPEAKER) 2P
*************************************************************
SW BOARD
*********
< SWITCH >
S801 1-762-875-21 SWITCH, KEYBOARD (?/1)
*************************************************************
SW (1) BOARD
************
< SWITCH >
S721 1-786-084-11 SWITCH, DETECTION (MAIN TRY IN/OUT)
*************************************************************
SW (2) BOARD
************
< SWITCH >
S731 1-786-382-11 SWITCH, PUSH (1 KEY) (SUB TRY IN)
*************************************************************
MISCELLANEOUS
**************
4 1-693-702-11 TUNER (FM/AM) (TM10SE)
(DX155: E3, MX, SP, AUS)
4 1-693-703-11 TUNER (FM/AM) (TM10SU)
(DX155: US, CND/DX255)
8 1-787-331-11 FAN, D.C.
9 1-828-953-11 WIRE (FLAT TYPE) (9 CORE)
67 1-828-384-11 WIRE (FLAT TYPE) (23 CORE)
102 1-828-369-11 WIRE (FLAT TYPE) (21 CORE)
103 1-828-331-11 WIRE (FLAT TYPE) (13 CORE)
RELAY SENSOR SPEAKER SW SW (1) SW (2)
