12
HCD-DZ110/DZ111/DZ120/DZ120K
3-2. CASE, FRONT PANEL ASSY
Note: Follow the disassembly procedure in the numerical order given.
9
connector (CN402) (DZ110/DZ111)
(CN312) (DZ120/DZ120K)
qf
connector (CN3001)
(EXCEPT DZ120K)
qd
w
ire (flat type)
23core (CN509)
1
The lever is moved in the direction
of the arrow with the thin rod.
2
3
loading panel
4
screw (CASE3 TP2)
5
screw
(CASE3 TP2)
7
case
qk
front panel assy
qg
three screws (+BV 3
×
6)
qj
claw
qh
claw
6
five screws
(+BVTP 3
×
8)
q;
two screws
(+BVTP 3
×
8)
When re-assembling, leave 30 mm between
harnesses A and B for safety.
harnesses A
harnesses B
clamp
30mm
qa
cover (top)
8
sheet
qs
sheet
