16
HCD-DZ110/DZ111/DZ120/DZ120K
3-10. TRAY
3-9. DVD MECHANISM DECK (CDM85-DVBU102)
1
two
screws
(+BVTP 3
×
8
qa
DVD mechanism deck
(CDM85-DVBU102)
8
cover (MD)
2
cover (top)
6
remove the wire and harness.
9
three
screws (+BV 3 x 6)
7
three
screws (+BV 3 x 6)
5
wire (flat type) 24
core
(CN1101)
4
wire (flat type) 5
core
(CN1202)
q;
wire (flat type) 5
core
3
connector (CN1201)
4
2
3
two claws
5
tray
1
Move the chuck cam
in the direction of the arrow.
bottom side
