15
HCD-DZ110/DZ111/DZ120/DZ120K
3-7. DC FAN, TUNER UNIT
7
DC fan
3
tuner unit
4
two
screws
(+BVTP 3
×
8)
5
cover (fan)
1
two screws (+BVTT 3
×
6)
6
two
screws
(+BVTT 4
×
8)
2
wire (flat type)
3-8. POWER BOARD
8
seven
screws
(+BV 3
×
8)
When re-assembling, attach the
heat radiation sheets on the
chassis, and then install the
POWER board.
radiation sheets
2
connector
(CN3001)
(EXCEPT DZ120K)
5
connector
(CN901)
6
connector
(CN3002)
7
connector
(CN515)
9
POWER board
1
connector
(CN312) (DZ120/DZ120K)
(CN302) (DZ110/DZ111)
3
two
screws
(+BVTP 3
×
8)
4
cover (top)
When re-assembling, leave 30 mm between
harnesses A and B for safety.
harnesses A
harnesses B
30mm
