HCD-DZ110/DZ111/DZ120/DZ120K
Fix the capacitors with adhesive agent as follows
Fixing the capacitors with adhesive agent is required by the safety regulation.
Be sure to fix the capacitors with adhesive agent when part or circuit board is replaced.
POWER BOARD
C910
C924 IC921
C930
%%
PRECAUTION WHEN INSTALLING A NEW OP UNIT /
PRECAUTION BEFOR UNSOLDERING THE STATIC ELECTRICIT
PREVENTION SOLDER BRIDGE
When installing a new OP unit, be sure to connect the flexible
printed circuit board first of all before removing the static electricity
prevention solder bridge by unsoldering. Remove the static electricity
prevention solder bridge by unsoldering after the flexible printed
circuit board has already been connected.
(Do not remove nor unsolder the solder bridge
as long as the OP unit is kept standalone.)
