84
HCD-DZ110/DZ111/DZ120/DZ120K
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R3427 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3551 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3553 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3554 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3555 1-216-864-11 SHORT CHIP 0
R4002 1-216-864-11 SHORT CHIP 0
< NETWORK RESISTOR >
RB501 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB1103 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1104 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1105 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1106 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1107 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1108 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1111 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1112 1-234-371-21 RES, NETWORK 47 (1005X4)
RB1113 1-234-371-21 RES, NETWORK 47 (1005X4)
RB1114 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1115 1-234-372-11 RES, NETWORK 100 (1005X4)
< VIBRATOR >
X502 1-795-058-21 VIBRATOR, CERAMIC 5MHz
X1102 1-813-539-11 QUARTZ CRYSTAL UNIT 27MHz
X3051 1-795-660-21 QUARTZ CRYSTAL UNIT 49.152MHz
*************************************************************
MS-203 BOARD, COMPLETE
***********************
< CONNECTOR >
CN001 1-815-412-11 CONNECTOR, FFC/FPC 5P
< SWITCH >
S001 1-786-693-11 SWITCH, DETECTION
*************************************************************
A-1144-737-A POWER BOARD, COMPLETE (DZ110/DZ111)
A-1144-950-A POWER BOARD, COMPLETE (DZ120: KR, RU)
A-1146-005-A POWER BOARD, COMPLETE
(DZ120: US, CND/DZ120K: TW)
A-1146-091-A POWER BOARD, COMPLETE (DZ120K: MX)
A-1159-363-A POWER BOARD, COMPLETE (DZ120K: E32)
A-1177-691-A POWER BOARD, COMPLETE (DZ120K: RU)
A-1178-742-A POWER BOARD, COMPLETE
(DZ120: AUS/DZ120K: EA, E3, E12, SP, AR)
***********************
< CAPACITOR >
0 C901 1-165-529-11 MYLAR 0.22uF 10 275V
0 C902 1-165-529-11 MYLAR 0.22uF 10 275V
0 C903 1-112-330-11 ELECT (BLOCK) 1000uF 20% 200V
(DZ120: US, CND/DZ120K: TW)
0 C903 1-112-331-11 ELECT (BLOCK) 1000uF 20% 250V
(DZ120K: MX)
0 C903 1-112-332-11 ELECT (BLOCK) 330uF 20% 400V
(DZ110/DZ111)
0 C903 1-112-333-11 ELECT (BLOCK) 330uF 20% 450V
(DZ120: KR, AUS, RU/
DZ120K: E3, E12, E32, RU, SP, AR, EA)
0 C905 1-112-334-91 FILM 0.01uF 5% 400V
(DZ120: US, CND/DZ120K: MX, TW)
0 C905 1-112-335-91 FILM 0.0033uF 5% 400V
(DZ110/DZ111/DZ120: KR, AUS, RU/
DZ120K: E3, E12, E32, RU, SP, AR, EA)
0 C906 1-117-815-31 FILM 1000PF 3% 1.5KV
(DZ110/DZ111/DZ120: KR, AUS, RU/
DZ120K: E3, E12, E32, RU, SP, AR, EA)
0 C906 1-117-828-31 FILM 3300PF 3% 1.5KV
(DZ120: US, CND/DZ120K: MX, TW)
0 C907 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(DZ110/DZ111/DZ120: KR, AUS, RU/
DZ120K: E3, E12, E32, RU, SP, AR, EA)
0 C907 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
(DZ120: US, CND/DZ120K: MX, TW)
0 C908 1-107-909-11 ELECT 47uF 20% 50V
0 C909 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
0 C910 1-107-906-11 ELECT 10uF 20% 50V
(DZ120: US, CND/DZ120K: MX, TW)
0 C910 1-126-965-91 ELECT 22uF 20% 50V
(DZ110/DZ111/DZ120: KR, AUS, RU/
DZ120K: E3, E12, RU, SP, AR, EA)
0 C910 1-107-909-11 ELECT 47uF 20% 50V
(DZ120K: E32)
0 C911 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
0 C913 1-117-693-11 CERAMIC 100PF 10% 250V
0 C918 1-113-925-11 CERAMIC 0.01uF 20% 250V
0 C920 1-113-925-11 CERAMIC 0.01uF 20% 250V
0 C922 1-128-560-11 ELECT 22uF 20% 100V
0 C923 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
0 C924 1-126-961-11 ELECT 2.2uF 20% 50V
0 C925 1-107-974-81 CERAMIC 47PF 5% 2KV
0 C928 1-113-896-11 CERAMIC 220PF 10% 250V
(DZ120: US, CND/DZ120K: MX, TW)
0 C928 1-113-900-11 CERAMIC 470PF 10% 250V
(DZ110/DZ111/DZ120: KR, AUS, RU/
DZ120K: E3, E12, E32, RU, SP, AR, EA)
0 C929 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
0 C930 1-117-693-11 CERAMIC 100PF 10% 250V
C932 1-100-924-21 ELECT 2200uF 20% 35V
C933 1-100-924-21 ELECT 2200uF 20% 35V
C934 1-112-831-11 ELECT 2200uF 20% 35V
(DZ120/DZ120K)
C934 1-126-953-11 ELECT 2200uF 20% 35V
(DZ110/DZ111)
C935 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C936 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C937 1-100-756-91 CERAMIC CHIP 0.047uF 50V
0 C938 1-113-898-11 CERAMIC 330PF 10% 250V
(DZ120: US, CND/DZ120K: MX, TW)
0 C938 1-117-698-51 CERAMIC 680PF 10% 250V
(DZ110/DZ111/DZ120: KR, AUS, RU/
DZ120K: E3, E12, E32, RU, SP, AR, EA)
C939 1-136-165-00 FILM 0.1uF 5% 50V
C940 1-128-947-31 ELECT 3300uF 20% 10V
C941 1-128-954-11 ELECT 1000uF 20% 25V
C942 1-126-941-11 ELECT 470uF 20% 25V
C943 1-126-933-11 ELECT 100uF 20% 16V
C944 1-128-951-21 ELECT 2200uF 20% 16V
MAIN MS-203 POWER
Ver. 1.3
