63
HCD-DZ150K/DZ151KB
Pin No. Pin Name I/O Description
48 DAMP LATCH2 O DAMP processor latch2
49 DAMP LATCH3 O DAMP processor latch3
50 DAMP INIT O DAMP processor reset
51 DAMP SOFT MUTE O DAMP processor soft muting
52 MIC2 SW I MIC2 insert switch
53 NO USE O Not used (Open)
54 NO USE O Not used (Open)
55 NO USE O Not used (Open)
56 FL_STB O FL driver chip select output
57 DC_DET I Speaker DC detect input
58 NO USE O Not used (Open)
59 NO USE O Not used (Open)
60 NO USE O Not used (Open)
61 NO USE O Not used (Open)
62 VCC — Power supply (BUP+3.3V)
63 MIC/A.CAL_SW I MIC insert switch
64 VSS — Ground terminal
65 DIAT_XRST O DIAT reset
66 DIAT_XSCEN O DIAT chip enable
67 NO USE O Not used (Open)
68 TUNED I TUNER tuned input
69 ST_CLK O TUNER clock output
70 ST_DO I TUNER data input
71 ST_CE O TUNER chip enable
72 ST_DI O TUNER data output
73 NO USE O Not used (Open)
74 KEY INT I Wakeup from ECO mode by key input
75 MIC_CLK O MIC electric volume clock output
76 MIC-DAT O MIC electric volume data output
77 DIAT_DET I DIAT ready detect input
78 NO USE O Not used
79 M_ST O LINK (Multi STEREO) control output
80 NO USE O Not used (Open)
81 ASEL3 O Audio selector 3 (not used)
82 V_SEL0 O Video selector 0
83 V_SEL1 O Video selector 1
84 ASEL0 O Audio selector 0
85 ASEL1 O Audio selector 1
86 ASEL2 O Audio selector 2 (not used)
87 NO USE O Not used
88 NO USE O Not used (Open)
89 CLINK_DET O C-Link detect input (not used (Open))
90 MONO/ST_DET I Front jack MONO or STEREO detect
91 A.CAL MIC LEVEL I MIC level detect for auto calibration
92 DESTINATION I Destination select input
93 MODEL I Model select input
94 KEY2 I Key input 2 input
95 KEY1 I Key input 1 input
96 VSS — Ground terminal
