HCD-DZ150K/DZ151KB
Pin No. Pin Name I/O Description
97 KEY0 I Key input 0 input
98 VREF — Reference voltage (E3.3V)
99 VCC — Power supply (BUP+3.3V)
100 NO USE O Not used
