71
HCD-DZ150K/DZ151KB
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Q304 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q305 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q307 8-729-027-52 TRANSISTOR DTC124EKA-T146
< RESISTOR >
R227 1-218-285-11 METAL CHIP 75 5% 1/10W
R228 1-218-285-11 METAL CHIP 75 5% 1/10W
R229 1-218-285-11 METAL CHIP 75 5% 1/10W
R305 1-216-833-11 METAL CHIP 10K 5% 1/10W
R306 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R307 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R312 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R314 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R321 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R323 1-218-285-11 METAL CHIP 75 5% 1/10W
R324 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R325 1-216-864-11 SHORT CHIP 0
R326 1-218-285-11 METAL CHIP 75 5% 1/10W
R332 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R333 1-216-841-11 METAL CHIP 47K 5% 1/10W
R334 1-216-841-11 METAL CHIP 47K 5% 1/10W
R339 1-218-285-11 METAL CHIP 75 5% 1/10W
R340 1-216-833-11 METAL CHIP 10K 5% 1/10W
R341 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R342 1-216-841-11 METAL CHIP 47K 5% 1/10W
R343 1-216-841-11 METAL CHIP 47K 5% 1/10W
R348 1-216-833-11 METAL CHIP 10K 5% 1/10W
R349 1-216-833-11 METAL CHIP 10K 5% 1/10W
R351 1-216-809-11 METAL CHIP 100 5% 1/10W
R352 1-216-833-11 METAL CHIP 10K 5% 1/10W
R353 1-216-833-11 METAL CHIP 10K 5% 1/10W
R356 1-216-833-11 METAL CHIP 10K 5% 1/10W
R360 1-216-821-11 METAL CHIP 1K 5% 1/10W
R361 1-216-809-11 METAL CHIP 100 5% 1/10W
R363 1-216-841-11 METAL CHIP 47K 5% 1/10W
R364 1-216-841-11 METAL CHIP 47K 5% 1/10W
R365 1-216-841-11 METAL CHIP 47K 5% 1/10W
R366 1-216-841-11 METAL CHIP 47K 5% 1/10W
R367 1-216-833-11 METAL CHIP 10K 5% 1/10W
R373 1-216-833-11 METAL CHIP 10K 5% 1/10W
R374 1-216-845-11 METAL CHIP 100K 5% 1/10W
R375 1-216-864-11 SHORT CHIP 0
R378 1-216-864-11 SHORT CHIP 0
R379 1-216-833-11 METAL CHIP 10K 5% 1/10W
R381 1-216-864-11 SHORT CHIP 0
R382 1-216-833-11 METAL CHIP 10K 5% 1/10W
R383 1-216-837-11 METAL CHIP 22K 5% 1/10W
R387 1-216-815-11 METAL CHIP 330 5% 1/10W
R388 1-215-865-11 METAL OXIDE 220 5% 1W
R389 1-216-864-11 SHORT CHIP 0
R390 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(EA)
R390 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(EXCEPT EA)
R392 1-216-833-11 METAL CHIP 10K 5% 1/10W
R394 1-216-821-11 METAL CHIP 1K 5% 1/10W
R396 1-216-833-11 METAL CHIP 10K 5% 1/10W
R398 1-216-833-11 METAL CHIP 10K 5% 1/10W
R399 1-216-833-11 METAL CHIP 10K 5% 1/10W
R400 1-216-821-11 METAL CHIP 1K 5% 1/10W
R402 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R403 1-216-845-11 METAL CHIP 100K 5% 1/10W
R404 1-216-845-11 METAL CHIP 100K 5% 1/10W
R405 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R406 1-216-845-11 METAL CHIP 100K 5% 1/10W
R407 1-216-845-11 METAL CHIP 100K 5% 1/10W
R408 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R409 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R410 1-216-841-11 METAL CHIP 47K 5% 1/10W
R411 1-216-841-11 METAL CHIP 47K 5% 1/10W
R412 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R413 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R414 1-216-817-11 METAL CHIP 470 0.5% 1/10W
(RU)
R414 1-216-864-11 SHORT CHIP 0 (EXCEPT RU)
R415 1-216-817-11 METAL CHIP 470 0.5% 1/10W
(RU)
R415 1-216-864-11 SHORT CHIP 0 (EXCEPT RU)
R416 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R417 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R420 1-216-817-11 METAL CHIP 470 5% 1/10W
R421 1-216-817-11 METAL CHIP 470 5% 1/10W
R426 1-216-864-11 SHORT CHIP 0
R427 1-216-864-11 SHORT CHIP 0
R430 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R436 1-216-833-11 METAL CHIP 10K 5% 1/10W
R437 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R438 1-216-833-11 METAL CHIP 10K 5% 1/10W
*************************************************************
A-1222-521-A JACK BOARD, COMPLETE (AUS, KR, RU, TW)
A-1239-706-A JACK BOARD, COMPLETE (EA)
A-1361-271-A JACK BOARD, COMPLETE
(E3, E12, E32, AR, MX, SP)
*********************
< CAPACITOR >
C401 1-124-589-11 ELECT 47uF 20% 16V
C403 1-124-584-00 ELECT 100uF 20% 10V
C404 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C405 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C406 1-124-584-00 ELECT 100uF 20% 10V
C410 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C411 1-126-157-11 ELECT 10uF 20% 16V
C412 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C413 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C420 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C421 1-126-157-11 ELECT 10uF 20% 16V
C422 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C423 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C431 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C432 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C433 1-162-925-11 CERAMIC CHIP 68PF 5% 50V
C434 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C440 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C441 1-126-157-11 ELECT 10uF 20% 16V
C442 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C443 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C471 1-124-222-91 ELECT 22uF 20% 6.3V
C491 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C493 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C849 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C850 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
JACKIO-S-OUT
Ver. 1.3
