72
HCD-DZ150K/DZ151KB
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< CONNECTOR >
CN806 1-779-550-21 CONNECTOR, FFC (LIF (NON-ZIF)) 13P
(EXCEPT EA)
CN806 1-818-172-11 CONNECTOR, FPC/FFC 13P (EA)
< DIODE >
D470 6-501-193-01 DIODE 1SS355WTE-17
D492 6-501-193-01 DIODE 1SS355WTE-17
D493 6-501-193-01 DIODE 1SS355WTE-17
D496 6-501-193-01 DIODE 1SS355WTE-17
D497 6-501-193-01 DIODE 1SS355WTE-17
< FERRITE BEAD >
FB470 1-500-236-22 BEAD, FERRITE (CHIP) (1608)
FB471 1-500-236-22 BEAD, FERRITE (CHIP) (1608)
FB474 1-500-236-22 BEAD, FERRITE (CHIP) (1608)
FB475 1-500-236-22 BEAD, FERRITE (CHIP) (1608)
< IC >
IC401 8-759-100-96 IC uPC4558G2
IC402 8-759-100-96 IC uPC4558G2
< JACK >
J401 1-819-878-21 JACK (AUDIO IN/MIC1/A.CAL MIC)
J402 1-819-878-21 JACK (MIC2)
< JUMPER RESISTOR >
JR816 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q470 1-801-806-11 TRANSISTOR DTC144EKA
Q471 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q473 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q474 8-729-027-24 TRANSISTOR DTA114TKA-T146
Q475 1-801-806-11 TRANSISTOR DTC144EKA
< RESISTOR >
R401 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R402 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R403 1-216-821-11 METAL CHIP 1K 5% 1/10W
R404 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R405 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R410 1-216-845-11 METAL CHIP 100K 5% 1/10W
R411 1-216-817-11 METAL CHIP 470 5% 1/10W
R412 1-216-837-11 METAL CHIP 22K 5% 1/10W
R413 1-216-821-11 METAL CHIP 1K 5% 1/10W
R414 1-216-835-11 METAL CHIP 15K 5% 1/10W
R415 1-216-821-11 METAL CHIP 1K 5% 1/10W
R416 1-216-801-11 METAL CHIP 22 5% 1/10W
R420 1-216-845-11 METAL CHIP 100K 5% 1/10W
R421 1-216-817-11 METAL CHIP 470 5% 1/10W
R422 1-216-837-11 METAL CHIP 22K 5% 1/10W
R423 1-216-821-11 METAL CHIP 1K 5% 1/10W
R424 1-216-821-11 METAL CHIP 1K 5% 1/10W
R431 1-216-864-11 SHORT CHIP 0
R432 1-216-837-11 METAL CHIP 22K 5% 1/10W
R433 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R434 1-216-864-11 SHORT CHIP 0
R435 1-216-857-11 METAL CHIP 1M 5% 1/10W
R440 1-216-845-11 METAL CHIP 100K 5% 1/10W
R441 1-216-817-11 METAL CHIP 470 5% 1/10W
R442 1-216-837-11 METAL CHIP 22K 5% 1/10W
R443 1-216-821-11 METAL CHIP 1K 5% 1/10W
R444 1-216-835-11 METAL CHIP 15K 5% 1/10W
R445 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
R470 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R471 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R472 1-216-819-11 METAL CHIP 680 5% 1/10W
R478 1-216-809-11 METAL CHIP 100 5% 1/10W
R480 1-216-805-11 METAL CHIP 47 5% 1/10W
R481 1-216-845-11 METAL CHIP 100K 5% 1/10W
R482 1-216-833-11 METAL CHIP 10K 5% 1/10W
R490 1-216-864-11 SHORT CHIP 0
R491 1-216-864-11 SHORT CHIP 0
R492 1-216-864-11 SHORT CHIP 0
R851 1-216-864-11 SHORT CHIP 0
R852 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R853 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R854 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R855 1-216-821-11 METAL CHIP 1K 5% 1/10W
R856 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R857 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R858 1-216-864-11 SHORT CHIP 0
< SWITCH >
S800 1-480-136-11 ENCODER, ROTARY (12 TYPE) (VOLUME)
S802 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
S803 1-762-875-21 SWITCH, KEYBOARD (.)
S804 1-762-875-21 SWITCH, KEYBOARD (X)
S805 1-762-875-21 SWITCH, KEYBOARD (x)
S806 1-762-875-21 SWITCH, KEYBOARD (>)
S807 1-762-875-21 SWITCH, KEYBOARD (A)
S808 1-762-875-21 SWITCH, KEYBOARD (H)
*************************************************************
A-1242-695-A MAIN BOARD, COMPLETE (E12)
A-1242-724-A MAIN BOARD, COMPLETE (AR)
9 A-1242-727-A MAIN BOARD, COMPLETE (RU)
A-1242-729-A MAIN BOARD, COMPLETE (E3)
A-1242-730-A MAIN BOARD, COMPLETE (E32, MX)
9 A-1249-182-A MAIN BOARD, COMPLETE (AUS)
A-1253-101-A MAIN BOARD, COMPLETE (SP)
A-1253-102-A MAIN BOARD, COMPLETE (EA)
*********************
< CAPACITOR >
C450 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C451 1-126-947-11 ELECT 47uF 20% 35V
C452 1-126-947-11 ELECT 47uF 20% 35V
C453 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C454 1-126-960-11 ELECT 1uF 20% 50V
C455 1-126-947-11 ELECT 47uF 20% 35V
C456 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C457 1-104-662-91 ELECT 22uF 20% 25V
C458 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C459 1-126-947-11 ELECT 47uF 20% 35V
C460 1-126-961-11 ELECT 2.2uF 20% 50V
C461 1-126-961-11 ELECT 2.2uF 20% 50V
C462 1-126-947-11 ELECT 47uF 20% 35V
C463 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
