84
HCD-DZ150K/DZ151KB
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SPEAKERPOWER P-SW
< VARISTOR >
0 VDR901 1-805-482-11 VARISTOR
*************************************************************
P-SW BOARD
**********
< CAPACITOR >
C851 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
< SWITCH >
S801 1-762-875-21 SWITCH, KEYBOARD (?/1)
*************************************************************
SPEAKER BOARD
**************
< CAPACITOR >
C301 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C302 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C303 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C304 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C305 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C306 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C307 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C308 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C309 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C310 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C311 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C312 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C313 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C314 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C315 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C316 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
* CN303 1-564-523-11 PLUG, CONNECTOR 8P
< TERMINAL GROUND >
ET301 1-537-738-21 TERMINAL, GROUND (EA)
ET302 1-537-738-21 TERMINAL, GROUND (EA)
< TERMINAL >
TB301 1-780-454-11 TERMINAL BOARD (SPEAKER) 4P
(SPEAKER/FRONT R,FRONT L,SUR R,SUR L)
*************************************************************
MISCELLANEOUS
**************
7 1-828-951-51 WIRE (FLAT TYPE) (9 CORE)
8 1-693-725-11 TUNER (FM/AM)(RU, KR)
8 1-693-726-11 TUNER (FM/AM)(AUS, EA, TW)
8 1-693-727-11 TUNER (FM/AM)(E3, E12, E32, AR, MX, SP)
59 1-828-325-51 WIRE (FLAT TYPE) (13 CORE)
61 1-828-374-51 WIRE (FLAT TYPE) (21 CORE)
102 1-828-292-51 WIRE (FLAT TYPE) (5 CORE)
103 1-828-349-51 WIRE (FLAT TYPE) (17 CORE)
104 1-828-316-51 WIRE (FLAT TYPE) (11 CORE)
109 1-787-331-11 FAN, D.C.
0 110 1-696-848-81 CORD, POWER (AUS)
0 110 1-769-079-23 CORD, POWER (KR)
0 110 1-777-071-23 CORD, POWER (E3, EA, SP)
0 110 1-827-226-41 CORD, POWER (MX)
0 110 1-827-597-41 CORD, POWER (TW)
0 110 1-829-387-11 CORD, POWER (AR)
0 110 1-830-188-11 CORD, POWER (RU, E12, E32)
114 1-828-319-51 WIRE (FLAT TYPE) (11 CORE)
0 507 8-820-321-05 OPTICAL PICK UP (KHM-313CAA/C2RP)
508 1-828-773-51 WIRE (FLAT TYPE)(24 CORE)
0 F901 1-533-311-12 FUSE, GLASS CYLINDRICAL (DIA.5)(8A/125V)
(MX, TW)
0 F901 1-533-949-33 FUSE, CYLINDRICAL (TIME LAG)(T8AL/250V)
(EA, E32)
0 F901 1-576-233-51 FUSE (H.B.C.) (T6.3AH/250V)
(RU, AR, E3, SP, E12, AUS, KR)
Ver. 1.3
