83
HCD-DZ150K/DZ151KB
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
POWER
IC943 6-705-308-01 IC SI-3010KM-TL
IC951 6-707-743-01 IC TA76L431S (TPE6, Q)
< COIL >
L931 1-457-438-11 INDUCTOR 5.6uH
L941 1-414-398-11 INDUCTOR 10uH
L942 1-414-398-11 INDUCTOR 10uH
L943 1-414-398-11 INDUCTOR 10uH
L944 1-414-398-11 INDUCTOR 10uH
L945 1-414-398-11 INDUCTOR 10uH
L947 1-414-398-11 INDUCTOR 10uH
L948 1-414-398-11 INDUCTOR 10uH
L951 1-414-398-11 INDUCTOR 10uH
L952 1-414-398-11 INDUCTOR 10uH (EXCEPT RU)
< LINE FILTER >
0 LF901 1-457-054-21 COIL, LINE FILTER
0 LF902 1-457-054-21 COIL, LINE FILTER
< PHOTO COUPLER >
0 PC901 6-600-438-01 IC TLP421F (D4-GR)
0 PC902 6-600-438-01 IC TLP421F (D4-GR)
0 PC903 6-600-438-01 IC TLP421F (D4-GR)
< TRANSISTOR >
0 Q901 8-729-141-88 TRANSISTOR 2SB1116A-TP-LK
0 Q921 8-729-142-51 TRANSISTOR 2SD1616A-TP-LK
Q943 1-801-806-11 TR DTC144EKA
Q945 6-550-718-01 TRANSISTOR RSR025N03TL
Q947 1-801-806-11 TR DTC144EKA
< RESISTOR >
0 R901 1-219-759-11 METAL 1M 5% 1/2W
0 R903 1-215-926-00 METAL OXIDE 33K 5% 3W F
(MX, TW)
0 R903 1-215-929-11 METAL OXIDE 100K 5% 3W F
(EXCEPT MX, TW)
0 R904 1-215-926-00 METAL OXIDE 33K 5% 3W F
(MX, TW)
0 R904 1-215-929-11 METAL OXIDE 100K 5% 3W F
(EXCEPT MX, TW)
0 R905 1-216-797-11 METAL CHIP 10 5% 1/10W
0 R906 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
0 R907 1-216-833-11 METAL CHIP 10K 5% 1/10W
0 R908 1-260-105-11 CARBON 3.3K 5% 1/2W
0 R909 1-216-845-11 METAL CHIP 100K 5% 1/10W
0 R910 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
0 R911 1-216-813-11 METAL CHIP 220 5% 1/10W
0 R912 1-216-361-61 METAL OXIDE 0.22 5% 2W F
(MX, TW)
0 R912 1-216-363-00 METAL OXIDE 0.33 5% 2W F
(EXCEPT MX, TW)
0 R913 1-216-361-61 METAL OXIDE 0.22 5% 2W F
(MX, TW)
0 R914 1-220-891-11 METAL PLATE 0.1 10% 5W F
(EXCEPT MX, TW)
0 R914 1-243-669-11 METAL 0.05 5% 5W F
(MX, TW)
0 R919 1-216-836-11 METAL CHIP 18K 5% 1/10W
0 R922 1-216-793-11 METAL CHIP 4.7 5% 1/10W
0R923 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
0R925 1-216-797-11 METAL CHIP 10 5% 1/10W
0R926 1-216-855-11 METAL CHIP 680K 5% 1/10W
0R927 1-216-348-00 METAL OXIDE 0.82 5% 1W F
(EA, E32, MX, TW)
0R927 1-216-349-00 METAL OXIDE 1 5% 1W F
(RU, AR, E3, SP, E12, AUS, KR)
0R929 1-246-106-11 METAL OXIDE 2.2 5% 1/2W F
R931 1-218-853-11 METAL CHIP 1.8K 0.5% 1/10W
(EA, E32)
R931 1-218-859-11 METAL CHIP 3.3K 0.5% 1/10W
(EXCEPT EA, E32)
R932 1-218-883-11 METAL CHIP 33K 0.5% 1/10W
R933 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R934 1-216-821-11 METAL CHIP 1K 5% 1/10W
R935 1-216-821-11 METAL CHIP 1K 5% 1/10W
R936 1-216-853-11 METAL CHIP 470K 5% 1/10W
R937 1-216-833-11 METAL CHIP 10K 5% 1/10W
R938 1-216-821-11 METAL CHIP 1K 5% 1/10W
R939 1-218-859-11 METAL CHIP 3.3K 0.5% 1/10W
R940 1-216-833-11 METAL CHIP 10K 5% 1/10W
R941 1-216-845-11 METAL CHIP 100K 5% 1/10W
R942 1-216-833-11 METAL CHIP 10K 5% 1/10W
R943 1-216-839-11 METAL CHIP 33K 5% 1/10W
R945 1-216-833-11 METAL CHIP 10K 5% 1/10W
R946 1-216-837-11 METAL CHIP 22K 5% 1/10W
R948 1-216-833-11 METAL CHIP 10K 5% 1/10W
R949 1-216-821-11 METAL CHIP 1K 5% 1/10W
R951 1-218-831-11 METAL CHIP 220 0.5% 1/10W
R952 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
R953 1-218-861-11 METAL CHIP 3.9K 0.5% 1/10W
R954 1-216-837-11 METAL CHIP 22K 5% 1/10W
R955 1-216-817-11 METAL CHIP 470 5% 1/10W
R956 1-216-821-11 METAL CHIP 1K 5% 1/10W
R957 1-216-841-11 METAL CHIP 47K 5% 1/10W
R958 1-216-821-11 METAL CHIP 1K 5% 1/10W
R960 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R962 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R965 1-218-865-11 METAL CHIP 5.6K 0.5% 1/10W
R966 1-216-821-11 METAL CHIP 1K 5% 1/10W
R967 1-216-821-11 METAL CHIP 1K 5% 1/10W
R968 1-216-821-11 METAL CHIP 1K 5% 1/10W
0R969 1-216-821-11 METAL CHIP 1K 5% 1/10W
R971 1-216-864-11 SHORT CHIP 0
R972 1-216-833-11 METAL CHIP 10K 5% 1/10W
R974 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
< TRANSFORMER >
0T901 1-443-649-11 TRANSFORMER, CONVERTER (MX, TW)
0T901 1-443-874-11 TRANSFORMER, CONVERTER
(EXCEPT MX, TW)
0T902 1-443-650-11 TRANSFORMER, CONVERTER
< THERMISTOR >
0TH901 1-805-841-21 THERMISTOR, NTC 3.0 (EA, E32, MX, TW)
0TH901 1-805-842-21 THERMISTOR, NTC 6.0
(RU, AR, E3, SP, E12, AUS, KR)
Ver. 1.2
