82
HCD-DZ150K/DZ151KB
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
0 C913 1-117-693-11 CERAMIC 100PF 10% 250V
0 C918 1-113-925-11 CERAMIC 0.01uF 20% 250V
0 C920 1-113-925-11 CERAMIC 0.01uF 20% 250V
0 C922 1-128-560-11 ELECT 22uF 20% 100V
0 C923 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
0 C924 1-126-961-11 ELECT 2.2uF 20% 50V
0 C925 1-107-974-81 CERAMIC 47PF 5% 2KV
0 C928 1-117-695-51 CERAMIC 220PF 10% 250V
(MX, TW)
0 C929 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
0 C930 1-117-693-11 CERAMIC 100PF 10% 250V
C932 1-100-924-21 ELECT 2200uF 20% 35V
C933 1-100-924-21 ELECT 2200uF 20% 35V
C934 1-112-831-11 ELECT 2200uF 20% 35V
C935 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C936 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C937 1-100-756-91 CERAMIC CHIP 0.047uF 50V
0 C938 1-117-696-51 CERAMIC 330PF 10% 250V
(MX, TW)
0 C938 1-117-697-51 CERAMIC 470PF 10% 250V
(EXCEPT MX, TW)
C939 1-136-165-00 FILM 0.1uF 5% 50V
C940 1-128-947-31 ELECT 3300uF 20% 10V
C941 1-128-954-11 ELECT 1000uF 20% 25V
C942 1-126-941-11 ELECT 470uF 20% 25V
C943 1-126-933-11 ELECT 100uF 20% 16V
C944 1-128-951-21 ELECT 2200uF 20% 16V
C945 1-126-935-11 ELECT 470uF 20% 16V
C946 1-128-950-21 ELECT 1000uF 20% 16V
C947 1-104-658-91 ELECT 100uF 20% 10V
C948 1-126-925-91 ELECT 470uF 20% 10V
C949 1-104-658-91 ELECT 100uF 20% 10V
C951 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C952 1-100-756-91 CERAMIC CHIP 0.047uF 50V
C953 1-117-214-11 CERAMIC 0.001uF 10% 2KV
C954 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C955 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C958 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C960 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C961 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
(EXCEPT RU)
0 C963 1-117-697-51 CERAMIC 470PF 10% 250V
(EXCEPT MX, TW)
0 C963 1-117-700-51 CERAMIC 0.0022uF 20% 250V
(MX, TW)
0 C964 1-117-697-51 CERAMIC 470PF 10% 250V
(EXCEPT MX, TW)
0 C964 1-117-700-51 CERAMIC 0.0022uF 20% 250V
(MX, TW)
C967 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C968 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C969 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C970 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C971 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C976 1-126-933-11 ELECT 100uF 20% 16V
0 C979 1-126-967-11 ELECT 47uF 20% 50V
(EA, E32)
0 C980 1-117-828-11 FILM 3300PF 3% 1.5KV
(MX, TW)
< CONNECTOR >
0 CN901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CN903 1-564-505-11 PLUG, CONNECTOR 2P (EXCEPT RU)
* CN906 1-564-714-11 PIN, CONNECTOR (SMALL TYPE) 12P
< DIODE >
D901 8-719-082-57 DIODE D5SBA60F01
0 D905 8-719-063-74 DIODE D1NL20U-TR2
0 D906 6-501-193-01 DIODE 1SS355WTE-17
0 D907 6-501-193-01 DIODE 1SS355WTE-17
0 D908 6-501-193-01 DIODE 1SS355WTE-17
0 D909 6-501-193-01 DIODE 1SS355WTE-17
0 D910 6-501-193-01 DIODE 1SS355WTE-17
0 D913 6-500-241-01 DIODE SARS03
0 D914 6-501-193-01 DIODE 1SS355WTE-17
0 D915 6-501-174-01 DIODE UDZW-TE17-10B
0 D921 6-501-424-01 DIODE STO2D-140
0 D922 8-719-063-74 DIODE D1NL20U-TR2
0 D923 6-501-174-01 DIODE UDZW-TE17-10B
0 D924 6-501-183-01 DIODE UDZW-TE17-24B
0 D925 6-501-167-01 DIODE UDZW-TE17-5.1B
0 D926 6-501-174-01 DIODE UDZW-TE17-10B
D931 6-501-849-01 DIODE FMX-22SL
D932 6-501-167-01 DIODE UDZW-TE17-5.1B
D941 6-500-288-11 DIODE EK19LF-F7
D942 8-719-080-53 DIODE RK36LF-B3
D943 8-719-080-53 DIODE RK36LF-B3
D944 6-500-288-11 DIODE EK19LF-F7
D945 6-501-181-01 DIODE UDZW-TE17-20B
< TERMINAL GROUND >
EB901 1-537-770-21 TERMINAL BOARD, GROUND (EXCEPT EA)
EB901 1-537-738-21 TERMINAL BOARD, GROUND (EA)
EB902 1-537-770-21 TERMINAL BOARD, GROUND (EXCEPT EA)
EB902 1-537-738-21 TERMINAL BOARD, GROUND (EA)
EB903 1-537-770-21 TERMINAL BOARD, GROUND (EXCEPT EA)
EB903 1-537-738-21 TERMINAL BOARD, GROUND (EA)
EB904 1-537-770-21 TERMINAL BOARD, GROUND (EXCEPT EA)
EB904 1-537-738-21 TERMINAL BOARD, GROUND (EA)
EB906 1-537-770-21 TERMINAL BOARD, GROUND (EXCEPT EA)
EB906 1-537-738-21 TERMINAL BOARD, GROUND (EA)
< FUSE HOLDER >
FH901 1-533-217-41 HOLDER, FUSE
FH902 1-533-217-41 HOLDER, FUSE
< FUSIBLE RESISTOR >
0 FR901 1-242-949-11 FUSIBLE 0.1 10% 1W
(RU, AR, E3, SP, E12, AUS, KR)
< IC >
0 IC901 6-707-741-01 IC STR-F6138-LF1352 (MX, TW)
0 IC901 6-707-742-01 IC STR-F6168-LF1352 (EXCEPT MX, TW)
0 IC921 6-707-740-01 IC STR-V153
IC931 8-759-648-34 IC TA76431AS (TPE6)
IC941 6-705-308-01 IC SI-3010KM-TL
IC942 6-705-308-01 IC SI-3010KM-TL
POWER
Ver. 1.2
