Sony HCD-EC70 - Optical Pick-Up (KSM-213 DCP), BD83 S Board

13
HCD-EC70
8 Remove soldering from
the four points.
7 wire (flat type) (16 core)
(CN301)
q; BD83S board
9 optical pick-up
(KSM-213DCP)
4 two screws (+PTPWHM 2.6)
1 two screws (+PTPWHM 2.6)
2 two coil springs (insulator)
3 two insulators
5 two coil springs (insulator)
6 two insulators
3-11. OPTICAL PICK-UP (KSM-213DCP), BD83S BOARD
