Sony HCD-EC70 - Belt (DLM3 A); Chassis (PT) Section

14
HCD-EC70
2 two screws
3 cover
4 belt (DLM3A)
5 belt (DLM3A)
1 two screws
1 two screws
(+BV3 × 10 )
2 four screws
(+BV3 × 10
)
3 rear cabint
5 four screws
(+BVTP4 × 12 )
4 Remove soldering from
the two points.
6 chassis (main mold)
8 HOLD board
7 screw
(+BV3 × 10 )
9 AC cord
3-12. BELT (DLM3A)
3-13. CHASSIS (PT) SECTION
