Sony HCD-EC70 - CD Mechanism Deck Section (BU-K6 BD83 S2-WOD)

50
HCD-EC70
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
7-5. CD MECHANISM DECK SECTION (BU-K6BD83S2-WOD)
201 A-1179-506-A BD83S BOARD, COMPLETE
202 4-985-672-01 SCREW (+PTPWHM2.6), FLOATING
203 4-227-045-31 SPRING (INSULATOR), COIL
204 4-227-549-11 INSULATOR
0205 A-4735-357-A OP BASE ASSY (KSM-213DHAP/ZRP1)
206 1-832-404-21 CABLE, FLEXIBLE FLAT (16 CORE)
207 1-797-193-12 MECHANICAL, CD
206
201
204
203
210
S201
205
204
211
211
212
203
209
202
202
204
203
202
202
204
203
208
207
not
supplied
not
supplied
not
supplied
not
supplied
208 2-632-062-01 BELT (DLM3A)
209 2-681-036-01 COVER (CD MECHA)
210 3-254-143-11 SCREW (B3), (+) BV TAPPING
211 2-633-134-01 SCREW (B2.6), (+) BV TAPPING
212 3-229-336-11 SCREW, +BVWH TAPPING
S201 1-771-853-11 SWITCH, DETECTION (LIMIT)
