Sony HCD-EC70 - Side Panel (R) and Side Panel (L); Top Section

7
HCD-EC70
4 two screws
(+BV3 × 10 )
9 Remove the top section
in the direction of the arrow.
7 connector
(CNP502)
8 connector
(CNP501)
5 two
claws
6 two
dowels
1 screw
(+KTP3 × 10 )
2 screw
(+KTP3 × 10 )
3 three screws
(+BV3 × 10 )
3-2. SIDE PANEL (R) AND SIDE PANEL (L)
3-3. TOP SECTION
3 side panel (R)
6 side panel (L)
5 two screws
(+BV3 × 10 )
2 two screws
(+BV3 × 10 )
1 four screws
(TP3 × 12 )
4 four screws
(TP3 × 12 )
Note: Follow the disassembly procedure in the numerical order given.
