59
HCD-EC70
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< RELAY >
RY131 1-755-307-11 RELAY
RY201 1-755-307-11 RELAY
< SWITCH >
SW501 1-762-369-11 SWITCH, SLIDE
< CABLE HOLDER >
WH171 1-819-972-11 HOLDER, CABLE 8P
< VIBRATOR >
X801 1-767-388-21 VIBRATOR, CRYSTAL 75KHz
*************************************************************
A-1171-060-A PANEL BOARD, COMPLETE
**********************
2-649-117-01 HOLDER (LCD)
2-649-178-01 PLATE, LIGHT GUIDE
2-649-179-01 SHEET (LCD)
2-665-175-01 SHEET (REFLECTOR)
< CAPACITOR >
C671 1-126-965-91 ELECT 22uF 20% 50V
C672 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C701 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C702 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C703 1-126-933-11 ELECT 100uF 20% 16V
C704 1-126-925-91 ELECT 470uF 20% 10V
C705 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C706 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C707 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C708 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C709 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C710 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C711 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C712 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C713 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C714 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C715 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C716 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C717 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C718 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C719 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C720 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C722 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C723 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C724 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C725 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C726 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C727 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C728 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C729 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C730 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C731 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C732 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C733 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C734 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C735 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C737 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C738 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C739 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C741 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C742 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C743 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
< CONNECTOR >
CNS671 1-784-735-11 CONNECTOR, FFC 13P
CNS701 1-779-295-11 CONNECTOR, FFC (LIF (NON-ZIF)) 27P
< DIODE >
D701 6-501-163-01 DIODE UDZW-TE17-3.6B
D702 8-719-000-07 DIODE MC2836
D703 8-719-062-51 DIODE 1PS226-115
< IC >
IC701 6-806-138-01 IC MB90802-108
IC703 6-600-446-01 IC RPM7240-H18 ( )
< JUMPER RESISTOR >
JR701 1-216-864-11 SHORT CHIP 0
JR702 1-216-864-11 SHORT CHIP 0
JR703 1-216-864-11 SHORT CHIP 0
JR704 1-216-864-11 SHORT CHIP 0
< COIL >
L701 1-216-864-11 SHORT CHIP 0
L702 1-216-864-11 SHORT CHIP 0
< LIQUID CRYSTAL DISPLAY >
LCD702 1-805-973-11 DISPLAY PANEL, LIQUID CRYSTAL
< LED >
LED701 6-501-479-01 DIODE 1L0341Y23E0CA602
LED702 8-719-060-44 DIODE SLR-342VRT32 (STANDBY)
< TRANSISTOR >
Q661 1-801-806-11 TRANSISTOR RT1N441C-TP-1
Q662 8-729-040-76 TRANSISTOR KTA1273-Y-AT
Q663 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
Q664 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q665 8-729-024-43 TRANSISTOR 2SA1365-T112-1EF
Q666 8-729-047-62 TRANSISTOR 2SC3440-T12-1F
Q667 8-729-024-43 TRANSISTOR 2SA1365-T112-1EF
Q668 8-729-047-62 TRANSISTOR 2SC3440-T12-1F
Q669 8-729-024-43 TRANSISTOR 2SA1365-T112-1EF
Q670 8-729-047-62 TRANSISTOR 2SC3440-T12-1F
Q671 8-729-024-43 TRANSISTOR 2SA1365-T112-1EF
Q672 8-729-047-62 TRANSISTOR 2SC3440-T12-1F
Q701 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q702 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
Q703 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
Q704 1-801-806-11 TRANSISTOR RT1N441C-TP-1
Q705 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
PANELMAIN
