61
HCD-EC70
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R779 1-216-809-11 METAL CHIP 100 5% 1/10W
R780 1-216-841-11 METAL CHIP 47K 5% 1/10W
R781 1-216-833-11 METAL CHIP 10K 5% 1/10W
R784 1-216-845-11 METAL CHIP 100K 5% 1/10W
R785 1-216-833-11 METAL CHIP 10K 5% 1/10W
R786 1-216-797-11 METAL CHIP 10 5% 1/10W
R787 1-216-805-11 METAL CHIP 47 5% 1/10W
R788 1-216-864-11 SHORT CHIP 0
< SWITCH >
SW700 1-786-417-11 ENCODER, ROTARY (VOLUME)
SW701 1-762-875-21 SWITCH, KEYBOARD (?/1)
SW702 1-762-875-21 SWITCH, KEYBOARD (DSGX)
SW703 1-762-875-21 SWITCH, KEYBOARD (+( ))
SW704 1-762-875-21 SWITCH, KEYBOARD (–( ))
SW705 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
SW706 1-762-875-21 SWITCH, KEYBOARD (EQ)
SW708 1-762-875-21 SWITCH, KEYBOARD (Z)
SW709 1-762-875-21 SWITCH, KEYBOARD (DISC 1)
SW710 1-762-875-21 SWITCH, KEYBOARD (DISC 2)
SW711 1-762-875-21 SWITCH, KEYBOARD (STOP x)
SW712 1-762-875-21 SWITCH, KEYBOARD (l/j)
SW713 1-762-875-21 SWITCH, KEYBOARD (L/J)
SW714 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
SW715 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
SW716 1-762-875-21 SWITCH, KEYBOARD (CD u)
SW719 1-762-875-21 SWITCH, KEYBOARD (DISC 3)
SW720 1-762-875-21 SWITCH, KEYBOARD (DISC SKIP/EX-CHANGE)
SW721 1-762-875-21 SWITCH, KEYBOARD
(PLAY MODE TUNING MODE)
< VIBRATOR >
X701 1-760-252-12 VIBRATOR, CRYSTAL 32768Hz
X702 1-795-054-51 VIBRATOR, CERAMIC 4.19MHz
*************************************************************
A-1171-072-A PT-AC BOARD, COMPLETE
*********************
< CAPACITOR >
0C051 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C052 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C053 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C054 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C055 1-164-005-11 CERAMIC CHIP 0.47uF 25V
< DIODE >
D051 6-500-334-01 DIODE MC2836-T112-1
D052 6-500-335-01 DIODE MC2838-T112-1
< COIL >
0L001 1-443-993-11 TRANSFORMER, LINE FILTER (LFT)
< TRANSFORMER >
0PT002 1-445-011-11 TRANSFORMER, POWER
< RESISTOR >
R051 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R052 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
< RELAY >
0RY001 1-755-334-11 RELAY, AC POWER
< CABLE HOLDER >
WH151 1-819-972-11 HOLDER, CABLE 8P
*************************************************************
A-1171-064-A TRANSISTOR BOARD, COMPLETE
***************************
< CAPACITOR >
C118 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C119 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
< IC >
IC101 8-759-701-59 IC TA7809S
*************************************************************
MISCELLANEOUS
**************
64 1-824-048-11 WIRE (FLAT TYPE) (27 CORE)
103 1-828-974-11 WIRE (FLAT TYPE) (13 CORE)
105 1-828-643-11 WIRE (FLAT TYPE) (23 CORE)
0114 1-790-757-51 CORD, POWER
159 1-797-575-21 DECK, MECHANICAL
0205 A-4735-357-A OP BASE ASSY (KSM-213DHAP/ZRP1)
206 1-832-404-21 CABLE, FLEXIBLE FLAT (16 CORE)
207 1-797-193-12 MECHANICAL, CD
M901 1-787-344-11 FAN, DC
0PT001 1-443-962-11 TRANSFORMER, POWER
S201 1-771-853-11 SWITCH, DETECTION (LIMIT)
PANEL PT-AC TRANSISTOR
