Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EC709iP/EC909iP
4545
JR607 1-216-864-11 SHORT CHIP 0
JR608 1-216-864-11 SHORT CHIP 0
JR609 1-216-864-11 SHORT CHIP 0
JR702 1-216-864-11 SHORT CHIP 0
JR802 1-216-864-11 SHORT CHIP 0
< COIL >
L081 1-457-757-11 COIL, AM ANTENNA
L097 1-481-758-21 INDUCTOR 0.033uH
L098 1-481-758-21 INDUCTOR 0.033uH
< TRANSISTOR >
Q601 8-729-120-28 TRANSISTOR 2SC1623-L5L6 (EC909iP)
Q602 8-729-120-28 TRANSISTOR 2SC1623-L5L6 (EC909iP)
Q603 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q604 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q605 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q606 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q701 6-551-270-01 TRANSISTOR 2SA2026
Q702 6-551-270-01 TRANSISTOR 2SA2026
Q703 6-551-270-01 TRANSISTOR 2SA2026
Q704 6-551-270-01 TRANSISTOR 2SA2026
Q803 8-729-120-28 TRANSISTOR 2SC1623-L5L6 (EC909iP)
Q804 8-729-120-28 TRANSISTOR 2SC1623-L5L6 (EC909iP)
Q805 6-551-270-01 TRANSISTOR 2SA2026 (EC909iP)
Q806 6-551-270-01 TRANSISTOR 2SA2026 (EC909iP)
< RESISTOR >
R086 1-216-864-11 SHORT CHIP 0
R091 1-216-813-11 METAL CHIP 220 5% 1/10W
R092 1-216-813-11 METAL CHIP 220 5% 1/10W
R093 1-216-813-11 METAL CHIP 220 5% 1/10W
R094 1-216-813-11 METAL CHIP 220 5% 1/10W
R095 1-216-809-11 METAL CHIP 100 5% 1/10W
R096 1-216-833-11 METAL CHIP 10K 5% 1/10W
R098 1-216-837-11 METAL CHIP 22K 5% 1/10W
R099 1-216-848-11 METAL CHIP 180K 5% 1/10W
R115 1-216-817-11 METAL CHIP 470 5% 1/10W
(EC909iP)
R116 1-216-817-11 METAL CHIP 470 5% 1/10W
(EC909iP)
R601 1-216-821-11 METAL CHIP 1K 5% 1/10W
(EC909iP)
R602 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(EC909iP)
R603 1-216-841-11 METAL CHIP 47K 5% 1/10W
(EC909iP)
R604 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EC909iP)
R605 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(EC909iP)
R606 1-216-821-11 METAL CHIP 1K 5% 1/10W
R607 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R608 1-216-833-11 METAL CHIP 10K 5% 1/10W
R609 1-216-833-11 METAL CHIP 10K 5% 1/10W
R610 1-216-821-11 METAL CHIP 1K 5% 1/10W
R611 1-216-841-11 METAL CHIP 47K 5% 1/10W
R612 1-216-845-11 METAL CHIP 100K 5% 1/10W
R613 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R614 1-216-833-11 METAL CHIP 10K 5% 1/10W
R615 1-216-833-11 METAL CHIP 10K 5% 1/10W
R616 1-216-817-11 METAL CHIP 470 5% 1/10W
R621 1-218-887-11 METAL CHIP 47K 0.5% 1/10W
R622 1-218-887-11 METAL CHIP 47K 0.5% 1/10W
R623 1-216-821-11 METAL CHIP 1K 5% 1/10W
R625 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R626 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R627 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R628 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R629 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R630 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R631 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R632 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R633 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R634 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R635 1-216-805-11 METAL CHIP 47 5% 1/10W
R636 1-216-805-11 METAL CHIP 47 5% 1/10W
R640 1-216-809-11 METAL CHIP 100 5% 1/10W
R641 1-216-813-11 METAL CHIP 220 5% 1/10W
R642 1-216-813-11 METAL CHIP 220 5% 1/10W
R643 1-216-821-11 METAL CHIP 1K 5% 1/10W
R644 1-216-821-11 METAL CHIP 1K 5% 1/10W
R645 1-216-833-11 METAL CHIP 10K 5% 1/10W
R646 1-216-833-11 METAL CHIP 10K 5% 1/10W
R647 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R648 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R649 1-216-835-11 METAL CHIP 15K 5% 1/10W
R650 1-216-835-11 METAL CHIP 15K 5% 1/10W
R651 1-216-821-11 METAL CHIP 1K 5% 1/10W
R652 1-216-821-11 METAL CHIP 1K 5% 1/10W
R653 1-216-833-11 METAL CHIP 10K 5% 1/10W
R654 1-216-833-11 METAL CHIP 10K 5% 1/10W
R655 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R656 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R659 1-216-835-11 METAL CHIP 15K 5% 1/10W
R660 1-216-835-11 METAL CHIP 15K 5% 1/10W
R661 1-216-837-11 METAL CHIP 22K 5% 1/10W
R662 1-216-837-11 METAL CHIP 22K 5% 1/10W
R663 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R664 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R665 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R666 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R667 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R668 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R669 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R670 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R671 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R672 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R677 1-216-809-11 METAL CHIP 100 5% 1/10W
R678 1-216-809-11 METAL CHIP 100 5% 1/10W
R693 1-216-864-11 SHORT CHIP 0
R701 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R702 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R703 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
(EC909iP)
R703 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
(EC709iP)
R704 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
(EC909iP)
R704 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
(EC709iP)
R705 1-216-841-11 METAL CHIP 47K 5% 1/10W
MAIN
