– 13 –
SECTION 5
DIAGRAMS
5-1. CIRCUIT BOARDS LOCATION
FUN/SURROUND boar
d
VOL/POWER board
TAPE PREAMP board
BD board
CD DOOR SW board
RELAY board
CONTROL BLK ASSY
THIS BLOCK IS SUPPLIED
AS THE ASSEMBLED BLOCK
DISPLAY board
FM/AM TUNER
THIS BLOCK IS SUPPLIED
AS THE ASSEMBLED BLOCK
