– 51 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R122 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R123 1-216-099-00 METAL CHIP 120K 5% 1/10W
R124 1-216-091-00 METAL CHIP 56K 5% 1/10W
R125 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R126 1-216-063-91 METAL GLAZE 3.9K 5% 1/10W
R127 1-216-089-91 METAL GLAZE 47K 5% 1/10W
R128 1-216-105-91 METAL GLAZE 220K 5% 1/10W
R129 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R130 1-216-079-00 METAL CHIP 18K 5% 1/10W
R131 1-216-079-00 METAL CHIP 18K 5% 1/10W
R132 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R133 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R134 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R135 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R136 1-216-073-00 METAL CHIP 10K 5% 1/10W
R137 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R138 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R139 1-216-033-00 METAL CHIP 220 5% 1/10W
R140 1-216-081-00 METAL CHIP 22K 5% 1/10W
R141 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R142 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R143 1-216-121-91 METAL GLAZE 1M 5% 1/10W
R144 1-216-073-00 METAL CHIP 10K 5% 1/10W
R145 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R146 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R147 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R148 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R149 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R150 1-216-037-00 METAL CHIP 330 5% 1/10W
R151 1-216-037-00 METAL CHIP 330 5% 1/10W
R152 1-216-037-00 METAL CHIP 330 5% 1/10W
R153 1-216-082-00 METAL GLAZE 24K 5% 1/10W
R154 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R156 1-216-085-00 METAL CHIP 33K 5% 1/10W
R157 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R158 1-216-001-00 METAL CHIP 10 5% 1/10W
< VARIABLE RESISTOR >
RV101 1-241-396-11 RES, ADJ, METAL GLAZE 22K
RV102 1-241-396-11 RES, ADJ, METAL GLAZE 22K
RV103 1-241-396-11 RES, ADJ, METAL GLAZE 22K
< SWITCH >
S101 1-572-085-11 SWITCH, LEAF (LIMIT)
< VIBRATOR >
X101 1-579-280-11 VIBRATOR, CRYSTAL (16.9344MHz)
**************************************************************
* A-4407-244-A CD DOOR SW BOARD, COMPLETE
***************************
< SWITCH >
S211 1-771-298-11 SWITCH, PUSH (CD DOOR)
**************************************************************
* A-4407-247-A DISPLAY BOARD, COMPLETE (AEP,UK,EE,CIS)
*************************************
* A-4407-248-A DISPLAY BOARD, COMPLETE (US,CND)
*********************************
* A-4407-249-A DISPLAY BOARD, COMPLETE (MY,SP,HK)
***********************************
4-997-381-01 LCD HOLDER
4-997-382-01 LIGHT BAR
4-997-383-01 DISPLAY FILTER
< CAPACITOR >
C200 1-126-514-11 ELECT 22uF 20% 16V
C201 1-102-962-00 CERAMIC 30PF 5% 50V
C202 1-102-953-00 CERAMIC 18PF 5% 50V
C203 1-136-165-00 FILM 0.1uF 5% 50V
C204 1-136-165-00 FILM 0.1uF 5% 50V
C205 1-126-916-11 ELECT 1000uF 20% 6.3V
C206 1-136-165-00 FILM 0.1uF 5% 50V
C207 1-136-165-00 FILM 0.1uF 5% 50V
C208 1-136-165-00 FILM 0.1uF 5% 50V
C209 1-136-165-00 FILM 0.1uF 5% 50V
C212 1-136-165-00 FILM 0.1uF 5% 50V
C213 1-126-177-11 ELECT 100uF 20% 10V
C220 1-136-165-00 FILM 0.1uF 5% 50V
C230 1-102-934-00 CERAMIC 1.0PF +-0.25PF 50V
C232 1-126-177-11 ELECT 100uF 20% 10V
< CONNECTOR >
* CN1 1-568-858-11 SOCKET, CONNECTOR 15P (AEP,UK,EE,CIS)
* CN1 1-784-568-11 CONNECTOR, FFC 13P (US,CND,SP,MY,HK)
< DIODE >
D201 8-719-920-76 DIODE 1S2076
D202 8-719-920-76 DIODE 1S2076
D203 8-719-920-76 DIODE 1S2076
D210 8-719-920-76 DIODE 1S2076
D211 8-719-920-76 DIODE 1S2076
D212 8-719-920-76 DIODE 1S2076
< IC >
IC201 8-759-497-90 IC TC9613
IC202 8-749-014-39 IC PIC-21041TH2
IC203 8-759-165-80 IC PST600C-T
< COIL >
L201 1-410-521-11 INDUCTOR 100uH
DISPLAYCD DOOR SWBD
