– 56 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R763 1-249-437-11 CARBON 47K 5% 1/4W
R765 1-249-437-11 CARBON 47K 5% 1/4W
R766 1-249-437-11 CARBON 47K 5% 1/4W
< VARIABLE RESISTOR >
VR701 1-230-499-11 RES, ADJ, CARBON 100K
VR702 1-230-499-11 RES, ADJ, CARBON 100K
VR703 1-230-497-11 RES, ADJ, CARBON 22K
VR704 1-230-497-11 RES, ADJ, CARBON 22K
VR705 1-230-495-11 RES, ADJ, CARBON 2K
VR706 1-230-495-11 RES, ADJ, CARBON 2K
**************************************************************
* A-4407-239-A VOL/POWER BOARD, COMPLETE
**************************
(AEP,UK,EE,CIS)
* A-4407-240-A VOL/POWER BOARD, COMPLETE (US,CND)
***********************************
* A-4407-241-A VOL/POWER BOARD, COMPLETE (MY,SP,HK)
*************************************
1-533-293-11 FUSE HOLDER
* 4-997-378-01 PC BOARD BRACKET
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
< CAPACITOR >
C403 1-136-173-00 FILM 0.47uF 5% 50V
C404 1-136-173-00 FILM 0.47uF 5% 50V
C461 1-126-960-11 ELECT 1uF 20% 50V
C462 1-126-960-11 ELECT 1uF 20% 50V
C463 1-137-364-11 FILM 0.001uF 5% 50V
C464 1-137-364-11 FILM 0.001uF 5% 50V
C465 1-137-378-11 FILM 0.22uF 5% 50V
C466 1-137-378-11 FILM 0.22uF 5% 50V
C469 1-126-933-11 ELECT 100uF 20% 16V
C470 1-126-925-11 ELECT 470uF 20% 10V
C471 1-162-851-11 CERAMIC 0.1uF 10% 16V
C475 1-126-964-11 ELECT 10uF 20% 50V
C476 1-126-964-11 ELECT 10uF 20% 50V
C477 1-137-399-11 FILM 0.1uF 5% 50V
C478 1-137-399-11 FILM 0.1uF 5% 50V
C479 1-126-948-11 ELECT 100uF 20% 35V
C480 1-126-948-11 ELECT 100uF 20% 35V
C481 1-102-106-00 CERAMIC 100PF 10% 50V
C482 1-102-106-00 CERAMIC 100PF 10% 50V
C483A 1-124-443-00 ELECT 100uF 20% 10V
C485 1-102-106-00 CERAMIC 100PF 10% 50V
C486 1-102-106-00 CERAMIC 100PF 10% 50V
C488 1-126-924-11 ELECT 330uF 20% 10V
C489 1-161-063-00 CERAMIC 0.1uF 10% 50V
C490 1-126-963-11 ELECT 4.7uF 20% 50V
C491 1-126-963-11 ELECT 4.7uF 20% 50V
C502 1-102-129-00 CERAMIC 0.01uF 10% 50V
C503 1-102-129-00 CERAMIC 0.01uF 10% 50V
C508 1-126-964-11 ELECT 10uF 20% 50V
C509 1-126-947-11 ELECT 47uF 20% 35V
C510 1-126-943-11 ELECT 2200uF 20% 25V
C511 1-126-951-11 ELECT 470uF 20% 35V
C512 1-126-924-11 ELECT 330uF 20% 10V
C513 1-126-924-11 ELECT 330uF 20% 10V
C514 1-126-933-11 ELECT 100uF 20% 16V
C515 1-126-933-11 ELECT 100uF 20% 16V
C516 1-162-851-11 CERAMIC 0.1uF 10% 16V
C517 1-162-851-11 CERAMIC 0.1uF 10% 16V
C518 1-162-851-11 CERAMIC 0.1uF 10% 16V
C519 1-126-923-11 ELECT 220uF 20% 10V
C520 1-126-923-11 ELECT 220uF 20% 10V
C521 1-162-851-11 CERAMIC 0.1uF 10% 16V
C522 1-126-924-11 ELECT 330uF 20% 10V
C523 1-126-924-11 ELECT 330uF 20% 10V
C525 1-126-924-11 ELECT 330uF 20% 10V
C526 1-126-924-11 ELECT 330uF 20% 10V
C527 1-162-851-11 CERAMIC 0.1uF 10% 16V
C528 1-126-924-11 ELECT 330uF 20% 10V
C529 1-126-933-11 ELECT 100uF 20% 16V
C530 1-162-851-11 CERAMIC 0.1uF 10% 16V
C531 1-162-851-11 CERAMIC 0.1uF 10% 16V
C532 1-126-933-11 ELECT 100uF 20% 16V
C999 1-161-772-11 CERAMIC 0.1uF 10% 25V
< DIODE >
D401 8-719-920-76 DIODE 1S2076
D402 8-719-920-76 DIODE 1S2076
D487 8-719-200-02 DIODE 10E2
D502 8-719-067-67 DIODE W02G
D503 8-719-001-64 DIODE UZL-12L2
D504 8-719-910-25 DIODE HZ12B2L
D506 8-719-001-85 DIODE UZL-12H3
D507 8-719-001-76 DIODE UZL-12M3
D508 8-719-001-42 DIODE UZL-11M1
D5098-719-935-81DIODE UZL-7L2
D510 8-719-200-02 DIODE 10E2
D511 8-719-920-76 DIODE 1S2076
< FUSE >
! F501 1-532-350-11 FUSE, TIME-LAG (T4AL 250V)
(AEP,UK,EE,CIS,MY,SP,HK)
! F501 1-532-746-11 FUSE, GLASS TUBE (4A 125V)(US,CND)
! F502 1-532-259-11 FUSE, TIME-LAG (T1.6AL 250V)
(AEP,UK,EE,CIS,MY,SP,HK)
! F502 1-532-742-11 FUSE, GLASS TUBE (1.6A 125V)(US,CND)
! F503 1-532-259-11 FUSE, TIME-LAG (T1.6AL 250V)
(AEP,UK,EE,CIS,MY,SP,HK)
! F503 1-532-742-11 FUSE, GLASS TUBE (1.6A 125V)(US,CND)
! F504 1-532-350-11 FUSE, TIME-LAG (T4AL 250V)
(AEP,UK,EE,CIS,MY,SP,HK)
! F504 1-532-746-11 FUSE, GLASS TUBE (4A 125V)(US,CND)
< IC >
IC461 8-759-497-88 IC TC9260P
IC472 8-759-261-93 IC NJM4580LD
IC501 8-759-701-57 IC NJM78M06FA
Les composants identifiés par
une marque ! sont critiques pour
la sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
TAPE PREAMP VOL/POWER
Ver 1.1 2001.06
