Sony HCD-EP303 - CD Mechanism and Cassette Lid Disassembly

10
HCD-EP303
3-6. CD Cabinet Section
1 two screws
(+BTP2.6
× 8
)
2 CD cabinet section
3-7. CD Mechanism Deck (CS-21SC-1280)
1 two screws
(BVTP3 × 10)
4 CD cover housing
8 vibration proof rubber
(pink)
8 vibration proof rubber
(pink)
6 four fiber washers
5 four pulley screws
8 vibration proof rubber
(orange)
8 vibration proof rubber
(orange)
9 CD mechanism deck (CS-21SC-1280)
6
3
7 two spring clamps
7 two spring clamps
2 Remove the connector.
