Sony HCD-EP303 - Printed Wiring Board DISPLAY Section

2525
HCD-EP303
6-8. Printed Wiring Board DISPLAY Section
• See page 16 for Circuit Boards Location.
IC601
IC603
REM601
IC602
DISPLAY BOARD
LED BOARD
LIQUID CRYSTAL DISPLAY
C
MAIN BOARD
CN302
(Page 21)
37
1
MEGA BASS
MUSIC MENU
+
–
VOLUME
VOLUME
D
MAIN BOARD
CN204
(Page 21)
K
A
+
–
TUNING
TUNING
+
–PRESET
SHUFFLE
REPEAT
TIMER
TAPE
CD
TUNER
TUNER MEM
E
E
E
K
A
K
K
K
K
E
A
A
A
A
K
K
A
A
US,CND
EXCEPT
AEP,UK
EXCEPT
AEP,UK
EXCEPT
AEP,UK
1
80
61
60
41
40
21
20
A
A
K
K
AK
AK
A
A
K
K
A
K
AK
AK
9
8
1
16
I
13
MAIN BOARD
CN101
A
(Page 21)
LCD BACK LIGHT
EXCEPT
AEP,UK
A
B
C
D
E
1 2 3 4 5 6
Ref. No. Location
D601 C-5
D602 C-4
D603 C-5
D607 B-3
D608 B-3
D609 C-2
D610 C-2
D611 C-1
D612 C-3
D613 C-3
D614 C-3
D615 C-3
D616 C-5
D617 D-3
D618 C-3
D619 A-6
D647 C-4
D648 C-5
IC601 A-4
IC602 C-2
IC603 A-2
Q601 B-5
Q602 C-5
Q603 D-4
Q604 C-5
REM601 B-2
• Semiconductor
Location
