Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
38
HCD-EP303
R643 1-249-433-11 CARBON 22K 5% 1/4W
R644 1-249-433-11 CARBON 22K 5% 1/4W
R645 1-249-437-11 CARBON 47K 5% 1/4W
R646 1-249-437-11 CARBON 47K 5% 1/4W
R647 1-249-437-11 CARBON 47K 5% 1/4W
R657 1-249-409-11 CARBON 220 5% 1/4W F
R658 1-249-437-11 CARBON 47K 5% 1/4W
R664 1-249-417-11 CARBON 1K 5% 1/4W F
R665 1-249-429-11 CARBON 10K 5% 1/4W
R666 1-249-437-11 CARBON 47K 5% 1/4W
(EXCEPT AEP, UK)
R667 1-249-437-11 CARBON 47K 5% 1/4W
R668 1-249-421-11 CARBON 2.2K 5% 1/4W F
(US, CND)
R669 1-249-437-11 CARBON 47K 5% 1/4W
< IC >
REM601 6-600-092-01 RPM7138-V4
< SWITCH >
SW601 1-570-472-11 SWITCH, KEY BOARD (?/1)
SW602 1-570-472-11 SWITCH, KEY BOARD (REPEAT)
SW603 1-570-472-11 SWITCH, KEY BOARD (SHUFFLE)
SW604 1-570-472-11 SWITCH, KEY BOARD (TUNER MEM)
SW605 1-570-472-11 SWITCH, KEY BOARD (PRESET -)
SW606 1-570-472-11 SWITCH, KEY BOARD (PRESET +)
SW607 1-554-088-00 SWITCH, KEY BOARD (M > TUNING +)
SW608 1-570-472-11 SWITCH, KEY BOARD (x)
SW609 1-554-088-00 SWITCH, KEY BOARD (. m TUNING -)
SW610 1-570-472-11 SWITCH, KEY BOARD (u)
SW611 1-570-472-11 SWITCH, KEY BOARD (CD)
SW612 1-570-472-11 SWITCH, KEY BOARD (TAPE)
SW613 1-570-472-11 SWITCH, KEY BOARD (TUNER)
SW614 1-570-472-11 SWITCH, KEY BOARD (MUSIC MENU)
SW615 1-570-472-11 SWITCH, KEY BOARD (MEGA BASS)
SW621 1-554-088-00 SWITCH, KEY BOARD (VOLUME -)
SW622 1-554-088-00 SWITCH, KEY BOARD (VOLUME +)
< VIBRATOR >
X602 1-795-398-11 VIBRATOR, CRYSTAL 6MHz
**************************************************************
A-4676-973-A HEADPHONE BOARD, COMPLETE
***************************
< JACK >
JK401 1-815-813-11 JACK (LARGE TYPE) (PHONES)
< RESISTOR >
R501 1-249-407-11 CARBON 150 5% 1/4W F
R502 1-249-407-11 CARBON 150 5% 1/4W F
**************************************************************
LED BOARD, COMPLETE
(included DISPLAY BOARD, COMPLETE)
**************************************
< DIODE >
D1 8-719-329-10 DIODE SEL2910D (LCD BACK LIGHT)
D2 8-719-329-10 DIODE SEL2910D (LCD BACK LIGHT)
D3 8-719-329-10 DIODE SEL2910D (LCD BACK LIGHT)
**************************************************************
A-4676-971-A MAIN BOARD, COMPLETE (AEP,UK)
A-4729-806-A MAIN BOARD, COMPLETE (EXCEPT AEP,UK)
************************************
1-424-881-11 AM BAR ANT
4-235-969-01 BAR HOLDER
7-682-549-09 SCREW +B 3X10
< TERMINAL >
ANT101 1-694-848-11 TERMINAL BOARD (ANT FM) (FM ANT)
< CAPACITOR >
C102 1-162-282-31 CERAMIC 100PF 10% 50V
C104 1-162-294-31 CERAMIC 0.001uF 10% 50V
C105 1-162-294-31 CERAMIC 0.001uF 10% 50V
C107 1-130-471-00 MYLAR 0.001uF 5% 50V
C108 1-126-963-11 ELECT 4.7uF 20.00% 50V
C109 1-102-936-00 CERAMIC 3.0PF
+-0.25PF
50V
C110 1-162-203-31 CERAMIC 15PF 5.00% 50V
C111 1-162-294-31 CERAMIC 0.001uF 10% 50V
C112 1-162-294-31 CERAMIC 0.001uF 10% 50V
C113 1-130-483-00 MYLAR 0.01uF 5% 50V
C114 1-130-483-00 MYLAR 0.01uF 5% 50V
C116 1-161-494-00 CERAMIC 0.022uF 25V
C117 1-130-481-00 MYLAR 0.0068uF 5% 50V
C118 1-130-481-00 MYLAR 0.0068uF 5% 50V
C119 1-126-960-11 ELECT 1uF 20.00% 50V
C120 1-126-960-11 ELECT 1uF 20.00% 50V
C121 1-162-290-31 CERAMIC 470PF 10% 50V
C122 1-126-957-11 ELECT 0.22uF 20.00% 50V
C123 1-126-959-11 ELECT 0.47uF 20.00% 50V
C124 1-126-960-11 ELECT 1uF 20.00% 50V
C126 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C127 1-127-884-11 CERAMIC 0.047uF 10% 50V
C128 1-126-935-11 ELECT 470uF 20.00% 10V
C129 1-126-963-11 ELECT 4.7uF 20.00% 50V
C130 1-126-964-11 ELECT 10uF 20.00% 50V
C131 1-127-884-11 CERAMIC 0.047uF 10% 50V
C132 1-102-518-11 CERAMIC 33PF 5.00% 50V
C133 1-128-815-11 CERAMIC 330PF 5% 50V
C134 1-162-294-31 CERAMIC 0.001uF 10% 50V
C135 1-110-342-11 MYLAR 390PF 5.00% 50V
C136 1-162-199-31 CERAMIC 10PF 5% 50V
C140 1-127-884-11 CERAMIC 0.047uF 10% 50V
C144 1-161-494-00 CERAMIC 0.022uF 25V
C145 1-162-282-31 CERAMIC 100PF 10% 50V
C146 1-162-294-31 CERAMIC 0.001uF 10% 50V
DISPLAY HEADPHONE LED MAIN
