NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
•Abbreviation
CND : Canadian model.
E51 : Chilean and Peruvian model.
MY : Malaysia model.
SP : Singapore model.
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
36
SECTION 8
ELECTRICAL PARTS LIST
HCD-EP303
AR : Argentine model.
MX : Mexican model.
AUS: Australian model.
CASSETTE
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
A-4676-974-A CASSETTE BOARD, COMPLETE
*************************
7-623-508-01 LUG, 3
< CAPACITOR >
C701 1-130-473-00 MYLAR 0.0015uF 5% 50V
C702 1-130-473-00 MYLAR 0.0015uF 5% 50V
C703 1-130-495-00 MYLAR 0.1uF 5% 50V
C704 1-130-495-00 MYLAR 0.1uF 5% 50V
C705 1-162-286-31 CERAMIC 220PF 10% 50V
C706 1-162-286-31 CERAMIC 220PF 10% 50V
C707 1-104-665-11 ELECT 100uF 20.00% 10V
C708 1-104-665-11 ELECT 100uF 20.00% 10V
C709 1-164-159-11 CERAMIC 0.1uF 50V
C710 1-164-159-11 CERAMIC 0.1uF 50V
C711 1-126-964-11 ELECT 10uF 20.00% 50V
C712 1-126-964-11 ELECT 10uF 20.00% 50V
C713 1-126-960-11 ELECT 1uF 20.00% 50V
C714 1-126-960-11 ELECT 1uF 20.00% 50V
C715 1-126-956-91 ELECT 0.1uF 20.00% 50V
C716 1-126-956-91 ELECT 0.1uF 20.00% 50V
C717 1-130-474-00 MYLAR 0.0018uF 5% 50V
C718 1-130-474-00 MYLAR 0.0018uF 5% 50V
C719 1-126-964-11 ELECT 10uF 20.00% 50V
C720 1-126-947-11 ELECT 47uF 20.00% 10V
C721 1-126-935-11 ELECT 470uF 20.00% 10V
C722 1-161-494-00 CERAMIC 0.022uF 25V
C723 1-128-551-11 ELECT 22uF 20.00% 25V
C725 1-130-476-00 MYLAR 0.0027uF 5% 50V
C727 1-161-494-00 CERAMIC 0.022uF 25V
C728 1-126-964-11 ELECT 10uF 20.00% 50V
C729 1-130-487-00 MYLAR 0.022uF 5% 50V
C730 1-130-481-00 MYLAR 0.0068uF 5% 50V
C731 1-162-282-31 CERAMIC 100PF 10% 50V
C732 1-162-282-31 CERAMIC 100PF 10% 50V
C733 1-162-294-31 CERAMIC 0.001uF 10% 50V
< CONNECTOR >
* CN701 1-695-645-11 PLUG (CONNECTOR) 4P
< DIODE >
D701 8-719-991-33 DIODE 1N4148TP
D702 8-719-991-33 DIODE 1N4148TP
< IC >
IC701 6-700-579-01 IC AN7312
< TRANSISTOR >
Q701 8-729-194-57 TRANSISTOR 2SC945TP-QP
Q702 8-729-194-57 TRANSISTOR 2SC945TP-QP
Q703 8-729-194-57 TRANSISTOR 2SC945TP-QP
Q704 8-729-194-57 TRANSISTOR 2SC945TP-QP
Q706 8-729-116-82 TRANSISTOR 2SD1616-L
< RESISTOR >
R701 1-249-393-11 CARBON 10 5% 1/4W F
R702 1-249-393-11 CARBON 10 5% 1/4W F
R703 1-249-434-11 CARBON 27K 5% 1/4W
R704 1-249-434-11 CARBON 27K 5% 1/4W
R705 1-249-434-11 CARBON 27K 5% 1/4W
R706 1-249-434-11 CARBON 27K 5% 1/4W
R707 1-249-418-11 CARBON 1.2K 5% 1/4W F
R708 1-249-418-11 CARBON 1.2K 5% 1/4W F
R709 1-249-413-11 CARBON 470 5% 1/4W F
R710 1-249-413-11 CARBON 470 5% 1/4W F
R711 1-249-440-11 CARBON 82K 5% 1/4W
R712 1-249-440-11 CARBON 82K 5% 1/4W
R713 1-249-431-11 CARBON 15K 5% 1/4W
R714 1-249-431-11 CARBON 15K 5% 1/4W
R715 1-249-429-11 CARBON 10K 5% 1/4W
R716 1-249-429-11 CARBON 10K 5% 1/4W
R719 1-249-426-11 CARBON 5.6K 5% 1/4W
R720 1-249-426-11 CARBON 5.6K 5% 1/4W
R721 1-249-429-11 CARBON 10K 5% 1/4W
R722 1-249-429-11 CARBON 10K 5% 1/4W
R723 1-247-893-11 CARBON 390K 5% 1/4W
R724 1-249-441-11 CARBON 100K 5% 1/4W
R725 1-249-411-11 CARBON 330 5% 1/4W
R726 1-249-437-11 CARBON 47K 5% 1/4W
R727 1-249-430-11 CARBON 12K 5% 1/4W
R728 1-249-437-11 CARBON 47K 5% 1/4W
R729 1-249-437-11 CARBON 47K 5% 1/4W
R730 1-249-437-11 CARBON 47K 5% 1/4W
R731 1-249-425-11 CARBON 4.7K 5% 1/4W F
R732 1-249-412-11 CARBON 390 5% 1/4W F
R735 1-249-435-11 CARBON 33K 5% 1/4W
R736 1-249-396-11 CARBON 18 5% 1/4W F
