6-10. Printed Wiring Board POWER Section
POWER BOARD
MAIN
BOARD
E
(Page 21)
AC
IN
TR401
POWER
TRANSFORMER
E
E
K
A
K
A
A
B
C
D
E
F
1 2 3 4 5
Ref. No. Location
D401 F-4
D402 F-3
D403 F-4
D404 F-4
D405 F-2
D406 F-3
D407 F-2
D408 F-3
D409 D-3
D411 D-4
D412 D-4
D413 D-4
D414 D-4
Q401 D-1
Q402 D-2
ZD401 E-2
• Semiconductor
Location
• See page 16 for Circuit Boards Location.
