Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
41
HCD-EP303
R233 1-249-437-11 CARBON 47K 5% 1/4W
R234 1-249-427-11 CARBON 6.8K 5% 1/4W F
R239 1-249-428-11 CARBON 8.2K 5% 1/4W F
R240 1-249-428-11 CARBON 8.2K 5% 1/4W F
R241 1-249-393-11 CARBON 10 5% 1/4W F
R242 1-247-843-11 CARBON 3.3K 5% 1/4W
R243 1-247-843-11 CARBON 3.3K 5% 1/4W
R245 1-249-427-11 CARBON 6.8K 5% 1/4W F
R246 1-249-437-11 CARBON 47K 5% 1/4W
R247 1-249-421-11 CARBON 2.2K 5% 1/4W F
R248 1-249-421-11 CARBON 2.2K 5% 1/4W F
R249 1-249-429-11 CARBON 10K 5% 1/4W
R250 1-249-429-11 CARBON 10K 5% 1/4W
R251 1-249-437-11 CARBON 47K 5% 1/4W
R252 1-249-437-11 CARBON 47K 5% 1/4W
R253 1-249-441-11 CARBON 100K 5% 1/4W
R254 1-249-429-11 CARBON 10K 5% 1/4W
R255 1-249-429-11 CARBON 10K 5% 1/4W
R256 1-249-429-11 CARBON 10K 5% 1/4W
R257 1-249-417-11 CARBON 1K 5% 1/4W F
R258 1-249-429-11 CARBON 10K 5% 1/4W
R264 1-249-422-11 CARBON 2.7K 5% 1/4W F
R265 1-249-422-11 CARBON 2.7K 5% 1/4W F
R266 1-249-429-11 CARBON 10K 5% 1/4W
R267 1-249-429-11 CARBON 10K 5% 1/4W
R268 1-249-429-11 CARBON 10K 5% 1/4W
R269 1-249-417-11 CARBON 1K 5% 1/4W F
R301 1-249-437-11 CARBON 47K 5% 1/4W
R302 1-249-437-11 CARBON 47K 5% 1/4W
R303 1-249-425-11 CARBON 4.7K 5% 1/4W F
R304 1-249-425-11 CARBON 4.7K 5% 1/4W F
R306 1-249-426-11 CARBON 5.6K 5% 1/4W
R308 1-249-410-11 CARBON 270 5% 1/4W F
R309 1-249-410-11 CARBON 270 5% 1/4W F
R310 1-249-385-11 CARBON 2.2 5% 1/6W F
R311 1-249-385-11 CARBON 2.2 5% 1/6W F
R312 1-249-398-11 CARBON 27 5% 1/4W F
R313 1-247-791-11 CARBON 22 5% 1/4W
(EXCEPT AEP,UK)
R318 1-249-399-11 CARBON 33 5% 1/4W F
R320 1-249-437-11 CARBON 47K 5% 1/4W
R321 1-249-413-11 CARBON 470 5% 1/4W F
R322 1-249-441-11 CARBON 100K 5% 1/4W
R323 1-249-425-11 CARBON 4.7K 5% 1/4W F
R324 1-249-441-11 CARBON 100K 5% 1/4W
R325 1-249-441-11 CARBON 100K 5% 1/4W
R327 1-249-416-11 CARBON 820 5% 1/4W F
R328 1-249-429-11 CARBON 10K 5% 1/4W
R329 1-249-409-11 CARBON 220 5% 1/4W F
R330 1-249-409-11 CARBON 220 5% 1/4W F
R331 1-249-429-11 CARBON 10K 5% 1/4W
R333 1-260-064-11 CARBON 1 5% 1/2W
R334 1-249-437-11 CARBON 47K 5% 1/4W
R341 1-249-429-11 CARBON 10K 5% 1/4W
R342 1-249-429-11 CARBON 10K 5% 1/4W
R343 1-249-429-11 CARBON 10K 5% 1/4W
R344 1-249-421-11 CARBON 2.2K 5% 1/4W F
R345 1-249-402-11 CARBON 56 5% 1/4W
(EXCEPT AEP,UK)
R346 1-249-402-11 CARBON 56 5% 1/4W
(EXCEPT AEP,UK)
< TERMINAL >
SPK301 1-537-238-11 TERMINAL BOARD (SPEAKER)
< SWITCH >
SW301 1-786-229-11 SWITCH, SLIDE (AM FREQ STEP)
(EXCEPT AEP, UK)
< COIL >
T102 1-424-877-11 COIL (AM OSC)
T103 1-424-876-11 COIL (AM)
< TRIMMER >
TC101 1-141-304-21 CAP, TRIMMER 10PF
TC102 1-141-227-00 CAP, TRIMMER 20PF
< DISCRIMINATOR/VIBRATOR >
X101 1-795-396-11 DISCRIMINATOR, CERAMIC 10.7MHz
X102 1-577-126-11 VIBRATOR, CRYSTAL 7.2MHz
< DIODE >
ZD302 8-719-929-15 DIODE MTZJ-T-72-9.1B
ZD304 8-719-110-17 DIODE MTZN-T-72-10B
ZD305 8-719-109-97 DIODE MTZJ-T-72-6.8B
**************************************************************
A-4676-975-A POWER BOARD, COMPLETE
(EXCEPT US,CND,MX)
A-4729-805-A POWER BOARD, COMPLETE (US,CND,MX)
**************************************
1-533-217-31 HOLDER, FUSE
< CAPACITOR >
C401 1-104-665-11 ELECT 100uF 20.00% 10V
C402 1-102-129-00 CERAMIC 10000PF 10% 50V
C403 1-126-935-11 ELECT 470uF 20.00% 16V
C404 1-102-129-00 CERAMIC 10000PF 10% 50V
C405 1-104-665-11 ELECT 100uF 20.00% 25V
C406 1-102-129-00 CERAMIC 10000PF 10% 50V
C407 1-104-665-11 ELECT 100uF 20.00% 25V
C408 1-102-129-00 CERAMIC 10000PF 10% 50V
C409 1-126-960-11 ELECT 1uF 20.00% 50V
0 C410 1-117-698-11 CERAMIC 680PF 10.00% 250V
C411 1-127-888-21 CERAMIC 0.1uF 10% 50V
< CONNECTOR >
* CN402 1-573-457-11 PLUG, CONNECTOR 6P
MAIN POWER
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
