Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
44
HCD-EP707
R382 1-249-429-11 CARBON 10K 5% 1/4W
R383 1-249-429-11 CARBON 10K 5% 1/4W
R384 1-249-417-11 CARBON 1K 5% 1/4W
R385 1-249-417-11 CARBON 1K 5% 1/4W
R386 1-249-429-11 CARBON 10K 5% 1/4W
R387 1-249-429-11 CARBON 10K 5% 1/4W
R388 1-249-433-11 CARBON 22K 5% 1/4W
R389 1-249-429-11 CARBON 10K 5% 1/4W
R390 1-249-429-11 CARBON 10K 5% 1/4W
R391 1-249-429-11 CARBON 10K 5% 1/4W
R392 1-249-429-11 CARBON 10K 5% 1/4W
R393 1-249-429-11 CARBON 10K 5% 1/4W
R394 1-249-429-11 CARBON 10K 5% 1/4W
R395 1-249-429-11 CARBON 10K 5% 1/4W
R396 1-249-429-11 CARBON 10K 5% 1/4W
0R397 1-215-857-11 METAL OXIDE 10 5% 1W F
R398 1-249-429-11 CARBON 10K 5% 1/4W
R401 1-249-435-11 CARBON 33K 5% 1/4W
R402 1-249-436-11 CARBON 39K 5% 1/4W
R403 1-249-436-11 CARBON 39K 5% 1/4W
R404 1-249-435-11 CARBON 33K 5% 1/4W
R405 1-249-421-11 CARBON 2.2K 5% 1/4W
R406 1-247-843-11 CARBON 3.3K 5% 1/4W
R407 1-247-843-11 CARBON 3.3K 5% 1/4W
R410 1-249-403-11 CARBON 68 5% 1/4W
R411 1-249-421-11 CARBON 2.2K 5% 1/4W
R412 1-249-424-11 CARBON 3.9K 5% 1/4W
R419 1-249-433-11 CARBON 22K 5% 1/4W
< COIL >
T201 1-456-181-11 COIL (OSCILLATION)
< TRIMMER/DIODE >
VC202 1-141-410-11 CAP, ADJ
VC203 8-719-070-77 DIODE SVC201SPA-M1-AC
VC204 8-719-070-77 DIODE SVC201SPA-M1-AC
VC205 1-141-410-11 CAP, ADJ
< DIODE >
Z201 8-719-109-89 DIODE MTZJ-T-72-5.6B
Z202 8-719-109-93 DIODE MTZJ-T-72-6.2B
Z203 8-719-109-89 DIODE MTZJ-T-72-5.6B
Z204 8-719-929-15 DIODE MTZJ-T-72-9.1B
**************************************************************
A-4730-429-A POWER AMP BOARD, COMPLETE
***************************
7-685-645-14 SCREW +BVTP 3X6 TYPE2 SLIT
7-685-646-14 SCREW +BVTP 3X8 TYPE2 SLIT
7-685-648-14 SCREW +BVTP 3X12 TYPE2 SLIT
< CAPACITOR >
C624 1-164-159-21 CERAMIC 0.1uF 50V
C700 1-128-818-21 CERAMIC 560PF 5% 50V
C701 1-128-818-21 CERAMIC 560PF 5% 50V
C702 1-162-282-31 CERAMIC 100PF 10% 50V
C703 1-162-282-31 CERAMIC 100PF 10% 50V
C704 1-130-495-00 MYLAR 0.1uF 5% 50V
C705 1-130-495-00 MYLAR 0.1uF 5% 50V
CE619 1-104-666-11 ELECT 220uF 20% 25V
CE700 1-126-964-11 ELECT 10uF 20% 50V
CE701 1-126-964-11 ELECT 10uF 20% 50V
CE702 1-126-933-11 ELECT 100uF 20% 16V
CE703 1-126-933-11 ELECT 100uF 20% 16V
CE704 1-104-665-11 ELECT 100uF 20% 25V
CE705 1-104-665-11 ELECT 100uF 20% 25V
CE707 1-126-943-11 ELECT 2200uF 20% 25V
CE708 1-126-943-11 ELECT 2200uF 20% 25V
CE709 1-126-971-11 ELECT 470uF 20% 50V
CE710 1-104-666-11 ELECT 220uF 20% 25V
CE711 1-126-967-11 ELECT 47uF 20% 50V
CE712 1-104-666-11 ELECT 220uF 20% 25V
< TRANSISTOR >
Q701 8-729-905-50 TRANSISTOR DTC343TS-TP
Q702 8-729-905-50 TRANSISTOR DTC343TS-TP
Q703 8-729-905-50 TRANSISTOR DTC343TS-TP
Q704 8-729-905-50 TRANSISTOR DTC343TS-TP
< RESISTOR >
R634 1-249-406-11 CARBON 120 5% 1/4W
R635 1-249-406-11 CARBON 120 5% 1/4W
R700 1-249-421-11 CARBON 2.2K 5% 1/4W
R701 1-249-421-11 CARBON 2.2K 5% 1/4W
R702 1-249-437-11 CARBON 47K 5% 1/4W
R703 1-249-437-11 CARBON 47K 5% 1/4W
R704 1-249-417-11 CARBON 1K 5% 1/4W
R705 1-249-437-11 CARBON 47K 5% 1/4W
R706 1-249-389-11 CARBON 4.7 5% 1/4W
R707 1-249-389-11 CARBON 4.7 5% 1/4W
R708 1-249-419-11 CARBON 1.5K 5% 1/4W
R709 1-249-419-11 CARBON 1.5K 5% 1/4W
R710 1-249-429-11 CARBON 10K 5% 1/4W
R711 1-249-422-11 CARBON 2.7K 5% 1/4W
R712 1-249-422-11 CARBON 2.7K 5% 1/4W
< IC >
U1 8-759-391-71 IC LA4450
U700 8-759-701-59 IC NJM7809FA
**************************************************************
A-4730-430-A REGULATOR BOARD, COMPLETE (US, CND)
A-4730-624-A REGULATOR BOARD, COMPLETE
(AEP, UK, AUS)
***************************
1-533-217-31 HOLDER, FUSE
< CAPACITOR >
C800 1-164-159-21 CERAMIC 0.1uF 50V
0C801 1-113-925-11 CERAMIC 0.01uF 20% 250V
C806 1-102-129-00 CERAMIC 10000PF 10% 50V
C807 1-102-129-00 CERAMIC 10000PF 10% 50V
C808 1-102-129-00 CERAMIC 10000PF 10% 50V
C809 1-102-129-00 CERAMIC 10000PF 10% 50V
C812 1-102-129-00 CERAMIC 10000PF 10% 50V
C821 1-164-159-21 CERAMIC 0.1uF 50V
MAIN POWER AMP REGULATOR
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
