Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
45
HCD-EP707
0C824 1-117-698-11 CERAMIC 680PF 10% 250V
C832 1-102-129-00 CERAMIC 10000PF 10% 50V
C833 1-102-129-00 CERAMIC 10000PF 10% 50V
C834 1-102-129-00 CERAMIC 10000PF 10% 50V
C838 1-164-159-21 CERAMIC 0.1uF 50V
C839 1-164-159-21 CERAMIC 0.1uF 50V
C840 1-102-129-00 CERAMIC 10000PF 10% 50V
C841 1-102-129-00 CERAMIC 10000PF 10% 50V
C847 1-102-129-00 CERAMIC 10000PF 10% 50V
C848 1-164-159-21 CERAMIC 0.1uF 50V
C849 1-164-159-21 CERAMIC 0.1uF 50V
C851 1-164-159-21 CERAMIC 0.1uF 50V
C852 1-164-159-21 CERAMIC 0.1uF 50V
C853 1-162-282-31 CERAMIC 100PF 10% 50V
CE802 1-126-943-11 ELECT 2200uF 20% 25V
CE803 1-126-968-11 ELECT 100uF 20% 50V
CE804 1-126-935-11 ELECT 470uF 20% 16V
CE806 1-126-933-11 ELECT 100uF 20% 16V
CE807 1-126-933-11 ELECT 100uF 20% 16V
CE811 1-126-968-11 ELECT 100uF 20% 50V
CE814 1-126-933-11 ELECT 100uF 20% 16V
CE815 1-126-933-11 ELECT 100uF 20% 16V
CE830 1-126-974-11 ELECT 3300uF 20% 50V
CE831 1-126-964-11 ELECT 10uF 20% 50V
CE833 1-126-960-11 ELECT 1uF 20% 50V
CE834 1-126-967-11 ELECT 47uF 20% 50V
CE836 1-126-942-61 ELECT 1000uF 20% 25V
CE838 1-126-933-11 ELECT 100uF 20% 16V
< CONNECTOR >
* CON801 1-569-596-11 PLUG, CONNECTOR (2.5mm) 3P
* CON806 1-564-711-11 PIN, CONNECTOR (SMALL TYPE) 9P
* CON808 1-564-104-00 PIN, CONNECTOR (3.96mm PITCH) 3P
* CON809 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P
* CON810 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P
< DIODE >
D800 8-719-991-33 DIODE 1N4148TP
D801 8-719-200-02 DIODE 1N4001
D802 8-719-077-63 DIODE 1N5402
D803 8-719-077-63 DIODE 1N5402
D804 8-719-077-63 DIODE 1N5402
D805 8-719-077-63 DIODE 1N5402
D806 8-719-200-02 DIODE 1N4001
D807 8-719-200-02 DIODE 1N4001
D808 8-719-200-02 DIODE 1N4001
D809 8-719-200-02 DIODE 1N4001
D810 8-719-200-02 DIODE 1N4001
D811 8-719-200-02 DIODE 1N4001
D812 8-719-200-02 DIODE 1N4001
D813 8-719-200-02 DIODE 1N4001
D816 8-719-200-02 DIODE 1N4001
D820 8-719-109-89 DIODE MTZJ-T-72-5.6B
D823 8-719-947-13 DIODE MTZJ-T-72-4.7B
D824 8-759-983-75 DIODE MTZJ-T-72-27
D830 8-719-991-33 DIODE 1N4148TP
D831 8-719-200-02 DIODE 1N4001
D832 8-719-109-85 DIODE MTZJ-T-72-5.1B
D833 8-719-991-33 DIODE 1N4148TP
D834 8-719-991-33 DIODE 1N4148TP
D836 8-719-200-02 DIODE 1N4001
D837 8-719-991-33 DIODE 1N4148TP
< COIL >
0L801 1-424-944-11 INDUCTOR 400uH
L802 1-410-093-11 INDUCTOR 39mH
< TRANSISTOR/IC >
Q801 8-729-194-57 TRANSISTOR 2SC945TP-QP
Q802 8-729-040-88 TRANSISTOR 2SB1240TV2QR
Q809 8-729-194-57 TRANSISTOR 2SC945TP-QP
Q821 8-729-438-33 TRANSISTOR 2SC1383-R
Q822 8-759-971-11 IC PST529D
< RESISTOR >
R804 1-249-417-11 CARBON 1K 5% 1/4W
R805 1-249-429-11 CARBON 10K 5% 1/4W
R809 1-249-417-11 CARBON 1K 5% 1/4W
R812 1-249-381-11 CARBON 1 5% 1/4W
R813 1-249-381-11 CARBON 1 5% 1/4W
R814 1-249-401-11 CARBON 47 5% 1/4W
R817 1-249-433-11 CARBON 22K 5% 1/4W
R823 1-249-409-11 CARBON 220 5% 1/4W
R824 1-249-429-11 CARBON 10K 5% 1/4W
R825 1-249-411-11 CARBON 330 5% 1/4W
R826 1-249-411-11 CARBON 330 5% 1/4W
R827 1-249-429-11 CARBON 10K 5% 1/4W
R834 1-249-413-11 CARBON 470 5% 1/4W
R835 1-249-400-11 CARBON 39 5% 1/4W
R836 1-249-433-11 CARBON 22K 5% 1/4W
R837 1-249-424-11 CARBON 3.9K 5% 1/4W
R839 1-249-424-11 CARBON 3.9K 5% 1/4W
0R841 1-219-237-91 SOLID 3.3M 20% 1/2W
(US, CND)
R842 1-249-429-11 CARBON 10K 5% 1/4W
R843 1-249-417-11 CARBON 1K 5% 1/4W
R844 1-247-807-31 CARBON 100 5% 1/4W
< RELAY >
0REL801 1-755-446-11 RELAY (AEP, UK, AUS)
0REL801 1-755-448-11 RELAY (US, CND)
< TRANSFORMER>
0TR801 1-437-956-11 TRANSFORMER, POWER (US, CND)
0TR801 1-437-958-11 TRANSFORMER, POWER (AEP, UK, AUS)
< IC >
U802 8-759-231-58 IC NJM7812A
**************************************************************
SPEAKER JACK BOARD
*******************
< CONNECTOR >
* CON800 1-564-215-11 PIN, CONNECTOR (3.96mm PITCH) 4P
REGULATOR SPEAKER JACK
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
To Next Page
