Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
46
HCD-EP707
< TERMINAL BOARD >
* SP801 1-537-240-21 TERMINAL BOARD (CHECKER IN)
(SPEAKER (IMPEDANCE USE 4Ω))
**************************************************************
SWITCH BOARD
*************
< SWITCH >
SW901 1-553-577-21 SWITCH, MICRO (CD MECHANISM PROTECT)
**************************************************************
VOL KEY BOARD
**************
< CAPACITOR >
C201 1-162-294-31 CERAMIC 0.001uF 10% 50V
C202 1-162-294-31 CERAMIC 0.001uF 10% 50V
< CONNECTOR >
* CON109 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
< LED >
LED101 8-719-941-07 LED SLC-22VR3 (STANDBY)
< TRANSISTOR >
Q103 8-729-173-38 TRANSISTOR 2SA608SP-G
< RESISTOR/ENCODER >
R110 1-249-427-11 CARBON 6.8K 5% 1/4W
R111 1-249-409-11 CARBON 220 5% 1/4W
R123 1-249-426-11 CARBON 5.6K 5% 1/4W
R124 1-249-422-11 CARBON 2.7K 5% 1/4W
R160 1-247-848-11 CARBON 5.1K 5% 1/4W
R214 1-249-429-11 CARBON 10K 5% 1/4W
R215 1-249-429-11 CARBON 10K 5% 1/4W
R216 1-476-916-11 ENCODER (VOLUME)
< SWITCH >
SW103 1-554-303-21 SWITCH, TACTILE (I/1)
SW104 1-554-303-21 SWITCH, TACTILE (MEGA BASS)
SW105 1-554-303-21 SWITCH, TACTILE (MUSIC MENU)
< DIODE >
Z201 8-719-109-85 DIODE MTZJ-T-72-5.1B
**************************************************************
SPEAKER JACK SWITCH VOL KEY
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
MISCELLANEOUS
**************
6 1-500-712-11 CORE, FERRITE
103 1-796-544-11 DECK, MECH (CRL4349)
152 1-176-636-11 PC BOARD ASSY
0157 1-555-750-00 CORD, POWER (AEP)
0157 1-696-535-11 CORD, POWER (UK)
0157 1-696-966-31 CORD, POWER (AUS)
0157 1-783-820-11 CORD, POWER (US, CND)
158 1-823-170-11 CORD (WITH CONNECTOR) (FM ANT)
(AEP, UK)
160 1-500-712-11 CORE, FERRITE
204 1-796-542-11 MECHANICAL, CD (CMCJ-0132)
0F803 1-533-296-11 FUSE, GLASS CYLINDRICAL (DIA.5)
(2A/125V) (US, CND)
0F803 1-533-468-11 FUSE, GLASS TUBE (DIA.5) (2A/250V)
(AEP, UK, AUS)
0F804 1-533-419-11 FUSE, GLASS CYLINDRICAL (DIA.5)
(4A/125V) (US, CND)
0F804 1-533-471-11 FUSE, GLASS TUBE (DIA.5) (4A/250V)
(AEP, UK AUS)
0TR800 1-437-955-11 TRANSFORMER, POWER (US, CND)
0TR800 1-437-957-11 TRANSFORMER, POWER (AEP, UK, AUS)
Ver 1.4
