SERVICE MANUAL
HCD-EP707
SUPPLEMENT-1
File this supplement with the service manual.
Subject: Addition of “DISASSEMBLY” and “ASSEMBLY”
of CD Mechanism deck
(SPM-03006)
US Model
Canadian Model
AEP Model
UK Model
Australian Model
Ver 1.3 2003.03
1. SERVICING NOTES
After assembling the CD mechanism deck, check that the drawer can be operated as shown in the figure below.
lever (slider-2)
1
Slide the lever (slider-2)
in the direction of arrow
A
,
at the full.
2
Slide the lever (slider-2)
in the direction of arrow
B
,
at the full.
3
front
-bottom view-
rear
lever (slider-2) lever (slider-2)
AB
drawer
To Next Page
