Pin No. Pin Name I/O Description
95 to 97 DGBP0 to DGBP2 I For debagger pin
98 O-CD-CL O Clock signal output for the CD-MP3 processor
99 I-CD-DO I Serial data input from the CD-MP3 processor
100 O-CD-M-MUTE O CD motor drive ON/OFF mute control signal output for the CD motor/coil driver
