55
HCD-EX66/EX88/EX99
SECTION 7
ELECTRICAL PARTS LIST
A-1800-482-A AMP SMPS BOARD, COMPLETE (EX66: EA)
A-1800-483-A AMP SMPS BOARD, COMPLETE
(EX66: EXCEPT EA)
*************************
7-685-647-71 SCREW +BVTP 3X10 TYPE2 IT-3
< CAPACITOR >
C600 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C601 1-100-831-91 CERAMIC CHIP 0.001uF 2% 50V
(EX66: EA)
C603 1-131-664-91 CERAMIC CHIP 0.15uF 10% 10V
C604 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C606 1-131-664-91 CERAMIC CHIP 0.15uF 10% 10V
C607 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C608 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C609 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C611 1-104-658-91 ELECT 100uF 20% 10V
C613 1-126-933-11 ELECT 100uF 20% 16V
C615 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C620 1-126-948-11 ELECT 100uF 20% 35V
C622 1-126-947-11 ELECT 47uF 20% 35V
C624 1-126-953-11 ELECT 2200uF 20% 35V
C625 1-126-951-11 ELECT 470uF 20% 35V
C626 1-126-951-11 ELECT 470uF 20% 35V
C627 1-126-951-11 ELECT 470uF 20% 35V
C628 1-126-951-11 ELECT 470uF 20% 35V
C637 1-137-198-81 FILM 1uF 5% 50V
C638 1-137-198-81 FILM 1uF 5% 50V
C639 1-137-198-81 FILM 1uF 5% 50V
C640 1-137-198-81 FILM 1uF 5% 50V
C641 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C642 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C643 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C644 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C645 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C646 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C647 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C648 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C649 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C650 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C651 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C652 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C653 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C654 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C655 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C656 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C657 1-126-960-11 ELECT 1uF 20% 50V
C658 1-126-964-11 ELECT 10uF 20% 50V
C659 1-100-881-91 CERAMIC CHIP 47uF 20% 6.3V
C660 1-100-881-91 CERAMIC CHIP 47uF 20% 6.3V
C661 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C662 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C663 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C664 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C665 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C666 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C667 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C668 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C676 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C677 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C678 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C679 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C700 1-126-941-11 ELECT 470uF 20% 25V
C701 1-126-964-11 ELECT 10uF 20% 50V
C702 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C703 1-126-947-11 ELECT 47uF 20% 35V
C705 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C706 1-126-964-11 ELECT 10uF 20% 50V
C707 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C708 1-126-947-11 ELECT 47uF 20% 35V
C709 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C710 1-126-951-11 ELECT 470uF 20% 35V
C713 1-104-658-91 ELECT 100uF 20% 10V
C714 1-135-977-31 ELECT 680uF 20% 10V
C716 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C717 1-126-961-11 ELECT 2.2uF 20% 50V
C718 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C719 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C720 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C721 1-126-963-11 ELECT 4.7uF 20% 50V
0 C902 1-112-869-51 CERAMIC 470PF 10% 250V
0 C903 1-112-869-51 CERAMIC 470PF 10% 250V
0 C905 1-114-594-21 FILM 0.22uF 10% 250V
0 C907 1-114-594-21 FILM 0.22uF 10% 250V
(EX66: EA)
0 C907 1-116-397-21 FILM 0.33uF 10% 250V
(EX66: EXCEPT EA)
0 C911 1-113-925-11 CERAMIC 0.01uF 20% 250V
0 C912 1-113-925-11 CERAMIC 0.01uF 20% 250V
0 C914 1-114-347-22 ELECT(BLOCK) 330uF 20% 450V
0 C916 1-112-869-51 CERAMIC 470PF 10% 250V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AMP SMPS (EX66)
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• CAPACITORS
uF: μF
• COILS
uH: μH
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
• Abbreviation
AR : Argentina model
E2 : 120V AC area in E model
E4 : 220 – 240V AC area in E model
E51 : Chilean and Peruvian models
EA : Saudi Arabia model
MX : Mexican model
To Next Page
