Sony HCD-EX99 - Parts List: AMP SMPS (EX88;EX99)

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EX66/EX88/EX99
5959
D943 6-501-849-01 DIODE FMX-22SL
D944 6-503-032-01 DIODE DZ2J180M0L
D967 6-502-961-01 DIODE DA2J10100L
D968 6-503-036-01 DIODE DZ2J220M0L
D969 6-503-032-01 DIODE DZ2J180M0L
D970 8-719-063-74 DIODE D1NL20U-TR2
D972 6-503-036-01 DIODE DZ2J220M0L
0 D975 6-502-234-01 DIODE EG01C LF-F7
0 D981 6-503-458-01 DIODE RK49LF-T1
D984 8-719-083-71 DIODE UDZSUSTE-1730B
D985 6-500-335-01 DIODE MC2838-T112-1
< FUSE >
0 F901 1-523-067-51 FUSE (T5AH/250V)
< IC >
IC600 8-759-278-58 IC NJM4558V-TE2
IC601 8-759-278-58 IC NJM4558V-TE2
IC602 6-712-613-01 IC SI-3010KM-TLS
IC603 6-701-680-01 IC PST3629NR
0 IC931 6-716-854-01 IC STR-X6768N
IC932 6-711-947-01 IC MM1431CURE
0 IC965 6-714-671-01 IC STR-Y6763
IC966 6-711-947-01 IC MM1431CURE
< JUMPER RESISTOR >
JR600 1-216-864-11 SHORT CHIP 0
JR601 1-216-864-11 SHORT CHIP 0
JR602 1-216-864-11 SHORT CHIP 0
JR603 1-216-864-11 SHORT CHIP 0
JR604 1-216-864-11 SHORT CHIP 0
JR605 1-216-864-11 SHORT CHIP 0
JR606 1-216-864-11 SHORT CHIP 0
JR607 1-216-864-11 SHORT CHIP 0
JR608 1-216-864-11 SHORT CHIP 0
< COIL >
L602 1-456-680-11 COIL, CHOKE 10uH
L603 1-456-680-11 COIL, CHOKE 10uH
L604 1-456-680-11 COIL, CHOKE 10uH
L605 1-456-680-11 COIL, CHOKE 10uH
L606 1-457-078-11 COIL, AIR-CORE
L607 1-457-077-11 COIL, AIR-CORE
L608 1-457-077-11 COIL, AIR-CORE
L609 1-457-078-11 COIL, AIR-CORE
0 L901 1-460-371-11 COIL, LINE FILTER
0 L902 1-460-371-11 COIL, LINE FILTER
L930 1-457-878-65 COIL, CHOKE 2.2uH
L969 1-457-578-11 COIL, CHOKE 10uH
< PHOTO COUPLER >
0 PH930 6-600-276-01 PHOTO COUPLER PS2561AL1-1-V-W
0 PH931 6-600-276-01 PHOTO COUPLER PS2561AL1-1-V-W
0 PH965 6-600-276-01 PHOTO COUPLER PS2561AL1-1-V-W
< TRANSISTOR >
Q600 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q601 6-551-699-01 TRANSISTOR ISA1602AM1-T111-1EF
Q602 8-729-038-37 TRANSISTOR RT1N141M-TP-1
Q603 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q604 6-551-699-01 TRANSISTOR ISA1602AM1-T111-1EF
Q605 6-551-699-01 TRANSISTOR ISA1602AM1-T111-1EF
Q606 6-551-699-01 TRANSISTOR ISA1602AM1-T111-1EF
Q607 6-551-699-01 TRANSISTOR ISA1602AM1-T111-1EF
Q608 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q930 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q932 6-551-678-01 TRANSISTOR 2SA1364-T111-1DE
Q933 8-729-038-42 TRANSISTOR RT1N441M-TP-1
Q934 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q935 8-729-038-42 TRANSISTOR RT1N441M-TP-1
Q965 8-729-056-46 TRANSISTOR 2SC5053T100Q
< RESISTOR >
R600 1-216-821-11 METAL CHIP 1K 5% 1/10W
R601 1-216-835-11 METAL CHIP 15K 5% 1/10W
R602 1-216-835-11 METAL CHIP 15K 5% 1/10W
R603 1-216-841-11 METAL CHIP 47K 5% 1/10W
R604 1-216-841-11 METAL CHIP 47K 5% 1/10W
R606 1-216-835-11 METAL CHIP 15K 5% 1/10W
R607 1-216-835-11 METAL CHIP 15K 5% 1/10W
R608 1-216-841-11 METAL CHIP 47K 5% 1/10W
R609 1-216-841-11 METAL CHIP 47K 5% 1/10W
R610 1-216-845-11 METAL CHIP 100K 5% 1/10W
R611 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R612 1-216-837-11 METAL CHIP 22K 5% 1/10W
R613 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R614 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R615 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
0 R616 1-243-669-11 METAL 0.05 5% 5W F
R617 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R618 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R619 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R620 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R621 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
R622 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
R623 1-216-853-11 METAL CHIP 470K 5% 1/10W
R624 1-216-837-11 METAL CHIP 22K 5% 1/10W
R625 1-216-833-11 METAL CHIP 10K 5% 1/10W
R626 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R627 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R628 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R629 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R630 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R631 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R632 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R633 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R634 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R635 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R636 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R637 1-216-837-11 METAL CHIP 22K 5% 1/10W
R638 1-216-837-11 METAL CHIP 22K 5% 1/10W
R639 1-216-841-11 METAL CHIP 47K 5% 1/10W
R640 1-216-845-11 METAL CHIP 100K 5% 1/10W
R641 1-216-849-11 METAL CHIP 220K 5% 1/10W
R642 1-216-849-11 METAL CHIP 220K 5% 1/10W
R643 1-216-849-11 METAL CHIP 220K 5% 1/10W
R644 1-216-849-11 METAL CHIP 220K 5% 1/10W
R645 1-216-849-11 METAL CHIP 220K 5% 1/10W
R646 1-216-849-11 METAL CHIP 220K 5% 1/10W
R651 1-216-841-11 METAL CHIP 47K 5% 1/10W
AMP SMPS (EX88)
