HCD-EX66/EX88/EX99
6
HOW TO OPEN THE TRAY WHEN POWER SWITCH TURN OFF
pin
bracket
Pull the tray by the hand.
CAPACITOR DISCHARGE FOR ELECTRIC SHOCK PREVENTION
AMP SMPS board
In checking the AMP SMPS board, make a capacitor
discharge of C624 (EX66) or C625 (EX88) or C631
(EX99) and C914 for electrical shock prevention.
(Right side view)
AMP SMPS board
C914
C624 (EX66)
C625 (EX88)
C631 (EX99)
800 :/2 W
800 :/2 W
