Sony HCD-EX99 - Parts List: AMP SMPS (EX99) & BD76

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EX66/EX88/EX99
6161
C657 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C658 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C659 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C660 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C661 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C662 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C663 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C664 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C665 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C666 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C667 1-100-881-91 CERAMIC CHIP 47uF 20% 6.3V
C668 1-100-881-91 CERAMIC CHIP 47uF 20% 6.3V
C669 1-100-881-91 CERAMIC CHIP 47uF 20% 6.3V
C670 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C671 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C672 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C673 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C674 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C675 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C676 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C677 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C678 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
0 C902 1-112-869-51 CERAMIC 470PF 10% 250V
0 C903 1-112-869-51 CERAMIC 470PF 10% 250V
0 C905 1-114-594-21 FILM 0.22uF 10% 250V
0 C907 1-116-397-21 FILM 0.33uF 10% 250V
0 C909 1-112-870-51 CERAMIC 0.001uF 20% 250V
0 C910 1-112-866-51 CERAMIC 100PF 10% 250V
0 C911 1-113-925-11 CERAMIC 0.01uF 20% 250V
0 C912 1-113-925-11 CERAMIC 0.01uF 20% 250V
0 C914 1-112-529-11 ELECT(BLOCK) 390uF 20% 450V
C930 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
0 C931 1-117-815-11 FILM 0.001uF 3% 1.5KV
0 C932 1-114-160-91 CERAMIC CHIP 1uF 10% 100V
C933 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C934 1-107-904-11 ELECT 3.3uF 20% 50V
C935 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C936 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
0 C937 1-128-562-11 ELECT 47uF 20% 100V
C938 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
0 C939 1-116-393-11 FILM 0.0033uF 5% 400V
0 C943 1-137-901-21 ELECT 1000uF 20% 63V
0 C944 1-137-901-21 ELECT 1000uF 20% 63V
C946 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C947 1-165-895-91 CERAMIC CHIP 0.1uF 10% 50V
0 C950 1-128-551-11 ELECT 22uF 20% 63V
C966 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
0 C967 1-117-220-81 CERAMIC 150PF 5% 2KV
C968 1-116-078-11 CERAMIC CHIP 1uF 10% 50V
C969 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C970 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
0 C971 1-107-930-91 ELECT 22uF 20% 100V
C972 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
0 C975 1-112-470-11 CERAMIC 470PF 10% 500V
C977 1-100-756-91 CERAMIC CHIP 0.047uF 10% 50V
C982 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C983 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C986 1-112-232-11 ELECT 2700uF 20% 16V
0 C989 1-128-551-11 ELECT 22uF 20% 63V
< CONNECTOR >
CN600 1-784-784-11 CONNECTOR, FFC 23P
CN601 1-842-646-11 CONNECTOR, BOARD TO BOARD 16P
CN602 1-842-797-11 CONNECTOR, BOARD TO BOARD 6P
CN901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
< DIODE >
D603 6-502-961-01 DIODE DA2J10100L
D604 6-502-961-01 DIODE DA2J10100L
0 D902 6-502-994-01 DIODE D10XB60 F
D930 6-503-040-01 DIODE DZ2J300M0L
D931 6-502-961-01 DIODE DA2J10100L
D932 6-503-040-01 DIODE DZ2J300M0L
D934 6-502-976-01 DIODE DZ2J150M0L
D935 6-502-961-01 DIODE DA2J10100L
D937 6-502-967-01 DIODE DZ2J06200L
D938 6-502-961-01 DIODE DA2J10100L
D939 6-502-961-01 DIODE DA2J10100L
0 D940 6-500-241-01 DIODE SARS03
D941 8-719-063-74 DIODE D1NL20U-TR2
D943 6-501-849-01 DIODE FMX-22SL
D944 6-503-032-01 DIODE DZ2J180M0L
D967 6-502-961-01 DIODE DA2J10100L
D968 6-503-036-01 DIODE DZ2J220M0L
D969 6-503-032-01 DIODE DZ2J180M0L
D970 8-719-063-74 DIODE D1NL20U-TR2
D972 6-503-036-01 DIODE DZ2J220M0L
0 D975 6-502-234-01 DIODE EG01C LF-F7
0 D981 6-503-458-01 DIODE RK49LF-T1
D984 8-719-083-71 DIODE UDZSUSTE-1730B
D985 6-500-335-01 DIODE MC2838-T112-1
< FUSE >
0 F901 1-523-042-51 FUSE (T6.3AH/250V)
< IC >
IC600 8-759-278-58 IC NJM4558V-TE2
IC601 8-759-278-58 IC NJM4558V-TE2
IC602 6-712-613-01 IC SI-3010KM-TLS
IC603 6-701-680-01 IC PST3629NR
0 IC931 6-716-854-01 IC STR-X6768N
IC932 6-711-947-01 IC MM1431CURE
0 IC965 6-714-671-01 IC STR-Y6763
IC966 6-711-947-01 IC MM1431CURE
< JUMPER RESISTOR >
JR600 1-216-864-11 SHORT CHIP 0
JR601 1-216-864-11 SHORT CHIP 0
JR602 1-216-864-11 SHORT CHIP 0
JR603 1-216-864-11 SHORT CHIP 0
JR604 1-216-864-11 SHORT CHIP 0
JR605 1-216-864-11 SHORT CHIP 0
JR606 1-216-864-11 SHORT CHIP 0
< COIL >
L601 1-456-680-11 COIL, CHOKE 10uH
L602 1-456-680-11 COIL, CHOKE 10uH
L603 1-456-680-11 COIL, CHOKE 10uH
L604 1-456-680-11 COIL, CHOKE 10uH
L605 1-457-078-11 COIL, AIR-CORE
AMP SMPS (EX99)
