Sony HCD-EX99 - Parts List: EFX-MODULE Panel

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EX66/EX88/EX99
6565
C826 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
(EX99)
C827 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
(EX99)
C828 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
(EX99)
C829 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
(EX99)
< CONNECTOR >
CN801 1-842-455-11 PIN HEADER 12P
CN802 1-842-458-11 PIN HEADER 6P
CN803 1-842-458-11 PIN HEADER 6P
< DIODE >
D804 6-503-454-01 DIODE P6SMBJ54A-5 (EX99)
D804 6-503-455-01 DIODE P6SMBJ40A-5 (EX88)
D805 6-503-454-01 DIODE P6SMBJ54A-5 (EX99)
D805 6-503-455-01 DIODE P6SMBJ40A-5 (EX88)
D806 6-503-454-01 DIODE P6SMBJ54A-5 (EX99)
D806 6-503-455-01 DIODE P6SMBJ40A-5 (EX88)
D807 6-503-454-01 DIODE P6SMBJ54A-5 (EX99)
D807 6-503-455-01 DIODE P6SMBJ40A-5 (EX88)
D808 6-503-543-01 DIODE SS110R3 (EX66)
D809 6-503-543-01 DIODE SS110R3 (EX66)
D810 6-503-543-01 DIODE SS110R3 (EX66)
D811 6-503-543-01 DIODE SS110R3 (EX66)
D815 6-500-335-01 DIODE MC2838-T112-1 (EX66)
D816 6-500-335-01 DIODE MC2838-T112-1 (EX66)
D817 6-500-848-01 DIODE MC2840-T112-1 (EX88/EX99)
D818 6-500-848-01 DIODE MC2840-T112-1 (EX88/EX99)
D819 6-500-848-01 DIODE MC2840-T112-1 (EX88/EX99)
D820 6-500-848-01 DIODE MC2840-T112-1 (EX88/EX99)
< GROUND TERMINAL >
ET800 1-780-434-11 TERMINAL, GROUND (ON BOARD CONTACT)
(EX66: EA)
ET801 1-780-434-11 TERMINAL, GROUND (ON BOARD CONTACT)
(EX66: EA)
< IC >
IC800 6-716-817-01 IC TAS5630BPHDR (EX99)
IC800
6-716-818-01 IC TAS5613APHDR (EX88)
IC800 6-716-819-01 IC TAS5611APHDR (EX66)
< RESISTOR >
R800 1-218-941-81
METAL CHIP 100 5% 1/16W
R802 1-218-941-81 METAL CHIP 100 5% 1/16W
R806 1-218-941-81 METAL CHIP 100 5% 1/16W
R808 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
(EX99)
R808 1-218-974-11 METAL CHIP 56K 5% 1/16W
(EX66/EX88)
R809 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R810 1-208-695-11 METAL CHIP 3.3K 0.5% 1/16W
(EX99)
R810 1-208-909-11 METAL CHIP 8.2K 0.5% 1/16W
(EX66/EX88)
R811 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R812 1-218-990-81 SHORT CHIP 0
R813 1-218-990-81 SHORT CHIP 0 (EX99)
R814 1-218-990-81 SHORT CHIP 0 (EX66/EX88)
R815 1-218-990-81 SHORT CHIP 0
R817 1-220-802-11 METAL CHIP 3.3 5% 1/16W
R818 1-220-802-11 METAL CHIP 3.3 5% 1/16W
R819 1-220-802-11 METAL CHIP 3.3 5% 1/16W
R820 1-220-802-11 METAL CHIP 3.3 5% 1/16W
R822 1-218-941-81 METAL CHIP 100 5% 1/16W
R823 1-218-941-81 METAL CHIP 100 5% 1/16W
R824 1-218-941-81 METAL CHIP 100 5% 1/16W
R825 1-218-941-81 METAL CHIP 100 5% 1/16W
*************************************************************
A-1800-425-A PANEL BOARD, COMPLETE (EX99: E2, E51, AR)
A-1800-426-A PANEL BOARD, COMPLETE (EX99: MX)
A-1800-428-A PANEL BOARD, COMPLETE (EX88: E2, E51, AR)
A-1800-429-A PANEL BOARD, COMPLETE (EX88: MX)
A-1800-432-A PANEL BOARD, COMPLETE (EX66: EA)
A-1800-433-A PANEL BOARD, COMPLETE (EX66: E2, E51, AR)
A-1800-434-A PANEL BOARD, COMPLETE (EX66: E4)
**********************
< CAPACITOR >
C301 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C308 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C309 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C318 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C319 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C320 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C322 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C323 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C325 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C328 1-126-157-11 ELECT 10uF 20% 16V
C329 1-124-234-00 ELECT 22uF 20% 16V
C331 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C333 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C335 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C336 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C337 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C342 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C343 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C344 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C345 1-124-584-00 ELECT 100uF 20% 10V
C353 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C356 1-126-518-11 ELECT 470uF 20% 4V
C359 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C360 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C361 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C362 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C363 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
(EX99)
C363 1-164-173-11 CERAMIC CHIP 0.0039uF 10% 50V
(EX66/EX88)
C364 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
(EX99)
C364 1-164-173-11 CERAMIC CHIP 0.0039uF 10% 50V
(EX66/EX88)
C365 1-124-234-00 ELECT 22uF 20% 16V
C366 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C367 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C370 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C371 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C372 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
EFX-MODULE PANEL
