Sony HCD-EX99 - Parts List: PANEL Components

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EX66/EX88/EX99
6767
< IC >
IC301 6-600-767-01 IC PNA4823M02S0 (IR)
IC302 A-1826-385-A IC LC87F7DJ2CVU-QIP-H (for SERVICE)
IC303 8-759-598-69 IC BA6956AN
IC304 6-714-881-01 IC MM1923DTRE
IC305 8-759-278-58 IC NJM4558V-TE2
IC306 6-713-384-01 IC BD3491FS-SE2
IC307 6-701-680-01 IC PST3629NR
IC308 8-759-359-49 IC NJM3414AV(TE2)
< JACK >
J301 1-842-550-11 JACK BLOCK, PIN 2P (DVD/PC IN)
J302 1-842-549-11 JACK (PHONES)
< JUMPER RESISTOR >
JR301 1-216-864-11 SHORT CHIP 0
JR302 1-216-864-11 SHORT CHIP 0
JR303 1-216-864-11 SHORT CHIP 0
JR304 1-216-864-11 SHORT CHIP 0
JR305 1-216-864-11 SHORT CHIP 0
JR306 1-216-864-11 SHORT CHIP 0
JR307 1-216-864-11 SHORT CHIP 0
JR308 1-216-864-11 SHORT CHIP 0
JR309 1-216-864-11 SHORT CHIP 0
JR310 1-216-864-11 SHORT CHIP 0
JR311 1-216-864-11 SHORT CHIP 0
JR313 1-216-864-11 SHORT CHIP 0
< LIQUID CRYSTAL DISPLAY >
ND301 1-811-042-11 DISPLAY PANEL, LIQUID CRYSTAL
< TRANSISTOR >
Q301 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q302 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q303 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q304 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q305 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q308 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q309 6-551-699-01 TRANSISTOR ISA1602AM1-T111-1EF
Q310 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q311 6-551-699-01 TRANSISTOR ISA1602AM1-T111-1EF (EX99)
Q312 8-729-620-13 TRANSISTOR 2SC4154TP-1EF (EX99)
Q313 8-729-620-13 TRANSISTOR 2SC4154TP-1EF (EX99)
Q314 8-729-620-13 TRANSISTOR 2SC4154TP-1EF (EX99)
Q315 8-729-620-13 TRANSISTOR 2SC4154TP-1EF (EX99)
Q316 8-729-620-13 TRANSISTOR 2SC4154TP-1EF (EX99)
Q317 8-729-620-13 TRANSISTOR 2SC4154TP-1EF (EX99)
Q319 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q321 6-551-699-01 TRANSISTOR ISA1602AM1-T111-1EF
Q324 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q325 8-729-043-90 TRANSISTOR IMX9T110
< RESISTOR >
R200 1-216-864-11 SHORT CHIP 0
R201 1-216-864-11 SHORT CHIP 0
R202 1-216-864-11 SHORT CHIP 0
R203 1-216-864-11 SHORT CHIP 0
R204 1-216-841-11 METAL CHIP 47K 5% 1/10W
R300 1-216-839-11 METAL CHIP 33K 5% 1/10W
R301 1-216-809-11 METAL CHIP 100 5% 1/10W
R304 1-216-809-11 METAL CHIP 100 5% 1/10W
R305 1-216-809-11 METAL CHIP 100 5% 1/10W
R306 1-216-839-11 METAL CHIP 33K 5% 1/10W
R307 1-216-817-11 METAL CHIP 470 5% 1/10W
R308 1-216-809-11 METAL CHIP 100 5% 1/10W
R309 1-216-807-11 METAL CHIP 68 5% 1/10W
R310 1-216-807-11 METAL CHIP 68 5% 1/10W
R311 1-216-803-11 METAL CHIP 33 5% 1/10W
R314 1-216-809-11 METAL CHIP 100 5% 1/10W
R315 1-216-803-11 METAL CHIP 33 5% 1/10W
R317 1-216-807-11 METAL CHIP 68 5% 1/10W
R318 1-216-821-11 METAL CHIP 1K 5% 1/10W
R319 1-216-809-11 METAL CHIP 100 5% 1/10W
R320 1-216-833-11 METAL CHIP 10K 5% 1/10W
R321 1-216-813-11 METAL CHIP 220 5% 1/10W
R322 1-216-833-11 METAL CHIP 10K 5% 1/10W
R323 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R324 1-216-845-11 METAL CHIP 100K 5% 1/10W
R325 1-216-845-11 METAL CHIP 100K 5% 1/10W
R326 1-216-845-11 METAL CHIP 100K 5% 1/10W
R327 1-216-817-11 METAL CHIP 470 5% 1/10W
R328 1-216-809-11 METAL CHIP 100 5% 1/10W
R329 1-216-809-11 METAL CHIP 100 5% 1/10W
R330 1-216-809-11 METAL CHIP 100 5% 1/10W
R331 1-216-809-11 METAL CHIP 100 5% 1/10W
R332 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R333 1-216-833-11 METAL CHIP 10K 5% 1/10W
R334 1-216-833-11 METAL CHIP 10K 5% 1/10W
R335 1-216-833-11 METAL CHIP 10K 5% 1/10W
R336 1-216-835-11 METAL CHIP 15K 5% 1/10W
R337 1-216-833-11 METAL CHIP 10K 5% 1/10W
R338 1-216-833-11 METAL CHIP 10K 5% 1/10W
R339 1-216-821-11 METAL CHIP 1K 5% 1/10W
R340 1-216-821-11 METAL CHIP 1K 5% 1/10W
R341 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R342 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R343 1-216-821-11 METAL CHIP 1K 5% 1/10W
R344 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R345 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R346 1-216-821-11 METAL CHIP 1K 5% 1/10W
R347 1-216-821-11 METAL CHIP 1K 5% 1/10W
R348 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R349 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R350 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R351 1-216-809-11 METAL CHIP 100 5% 1/10W
R352 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R353 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R354 1-216-821-11 METAL CHIP 1K 5% 1/10W
R355 1-216-821-11 METAL CHIP 1K 5% 1/10W
R356 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R357 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R358 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R359 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R360 1-216-809-11 METAL CHIP 100 5% 1/10W
R361 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R362 1-216-809-11 METAL CHIP 100 5% 1/10W
R363 1-216-809-11 METAL CHIP 100 5% 1/10W
R364 1-216-845-11 METAL CHIP 100K 5% 1/10W
R365 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
PANEL
