Sony HCD-GN1100D - IC Pin Function Descriptions (Continued)

Sony HCD-GN1100D
106 pages
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Loading...
71
HCD-GN1100D
47 A-HALF I Deck A cassette detection signal input terminal ("H": cassette detected)
48 A-TRIG O Deck A side trigger plunger drive signal output ("H": plunger on)
49 B-TRIG O Deck B side trigger plunger drive signal output ("H": plunger on)
50 CAPM-CONT O Capstan motor drive signal output
51 SW-SPK RELAY O Relay drive signal output for the passive sub woofer ("H": relay on)
52 REC BIAS O Recording bias on/off control signal output ("H": bias on)
53 TC-RELAY O Recording/playback selection signal output ("H": recording "L": playback)
54 REC-MUTE O Recording muting on/off control signal output ("L":muting on)
55 PB-A/B O Deck A/B playback selection signal output ("H": deck A "L": deck B)
56 ALC O Automatic limiter control signal output ("H": limiter on)
57 EFFECTOR - CTR 1 O Effector circuity mode control 1 output ("L": Delay 1, Delay 2, Effector Off
"H": Flanger 1, Flanger 2, Chorus 1, Chorus 2)
58 FAN HI SPEED O Fan speed control signal use in Thermal VACS output ("L": high speed)
59 NO USE - Ground terminal
60 STK-MUTE O Power amplifier and sub woofer amplifier on/off control signal output
("H": amplifier on)
61 SURR-RELAY O Relay drive signal output for the surround speakers ("H": relay on)
62 VCC - Power supply terminal (+3.3V)
63 NO USE - Ground terminal
64 VSS - Ground terminal
65 CENTER-RELAY O Relay drive signal output for the center speaker ("H": relay on)
66 FRONT-RELAY O Relay drive signal output for the front speakers ("H": relay on)
67 PROTECTOR I Speaker protect detection signal input from speaker protect circuit ("L": protector on)
68 OVER VOLTAGE DET I Over-voltage protection detection input ("L": over-voltage detected)
69 UNDER VOLTAGE DET I "Under-voltage protection detection input ("L": under-voltage detected)
70 EFFECTOR - CTR 3 O Effector circuity mode control 3 output ("L": Chorus 1, Chorus 2, Effector Off
"H": Flanger 1, Flanger 2, Delay 1, Delay 2)
71 TC-MUTE O Tape playback muting on/off control signal output ("H": muting on)
72 HP-MUTE O Headphone muting on/off control signal ("H": muting on)
73 DISPLAY-KEY I DISPLAY key press detection signal (Interrupt input)
74 POWER-KEY I POWER key press detection signal (Interrupt input)
75 SW-MUTE O Subwoofer muting on/off control signal output ("L": muting on)
76 LINE-MUTE O Line muting on/off control signal ("H": muting on)
77 DVD-A-MUTE O DVD motherboard analog output signal muting on/off control signal output
("H": muting on)
78 MTK-POWER O Power supply control signal to DVD motherboard ("H": power supply on)
79 AUDIO-IC-DATA O Serial data output to audio signal processor, M61529FP
80 AUDIO-IC-CLK O Serial data transfer clock signal output to audio signal processor, M61529FP
81 VOLUME-IC-DATA O Serial data output to 4-ch volume IC, M61530FP
82 VOLUME-IC-CLK O Serial data transfer clock signal output to 4-ch volume IC, M61530FP
83 AUDIO-OUT-MUTE O Audio out muting on/off control signal ("H": muting on)
84 HP-DETECT I Headphone connection detection signal input ("H": headphone connected)
85 MIC-DETECT I Microphone connection detection signal input ("L": headphone connected)
86 NO USE - Ground terminal
87 VIDEO-OUT-SW O Composite video output switching output control ("L": DVD VIDEO output
"H": VIDEO VIDEO input)
88 VIDEO MUTE O Video muting on/off control signal output ("L": muting on)
89 A-SHUT I Shut off detection signal input from deck A side reeel pulse detector (A/D input)
90 B-SHUT I Shut off detection signal input from deck A side reeel pulse detector (A/D input)
Pin No. Pin Name I/O Description
