Sony HCD-GN1100D - Electrical Parts List (Continued); Main Board (MIC Section) Parts

85
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-GN1100D
DRIVERDMB16
R3743 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R3744 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R3745 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3746 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3747 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3748 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3749 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3751 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R3752 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R3753 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R3754 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R3755 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3756 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3757 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3758 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3759 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3761 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R3762 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R3763 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R3764 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R3765 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3766 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3767 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3768 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3769 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3771 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R3772 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R3773 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R3774 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R3775 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3776 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3777 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3778 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3779 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3781 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R3782 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R3783 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R3784 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R3785 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3786 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3787 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3788 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3789 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3801 1-216-864-11 SHORT CHIP 0 (EXCEPT EA)
R3801 1-400-330-21 INDUCTOR, FERRITE BEAD (1608) (EA)
R3802 1-216-864-11 SHORT CHIP 0
R3803 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3804 1-216-836-11 METAL CHIP 18K 5% 1/10W
R3805 1-216-821-11 METAL CHIP 1K 5% 1/10W
R4701 1-216-864-11 SHORT CHIP 0
R4702 1-216-864-11 SHORT CHIP 0
R4703 1-216-864-11 SHORT CHIP 0
R4704 1-216-864-11 SHORT CHIP 0
R4705 1-216-864-11 SHORT CHIP 0
R4706 1-216-864-11 SHORT CHIP 0
R5001 1-216-864-11 SHORT CHIP 0
R5016 1-216-864-11 SHORT CHIP 0 (E3, E12, E15, EA)
R5017 1-216-864-11 SHORT CHIP 0 (SP, MY, TH, PH)
< COMPOSITION CIRCUIT BLOCK >
RB103 1-234-371-21 RES, NETWORK 47 (1005X4)
RB104 1-234-371-21 RES, NETWORK 47 (1005X4)
RB105 1-234-370-21 RES, NETWORK 22 (1005X4)
RB106 1-234-370-21 RES, NETWORK 22 (1005X4)
RB107 1-234-371-21 RES, NETWORK 47 (1005X4)
RB108 1-234-372-11 RES, NETWORK 100 (1005X4)
RB111 1-234-371-21 RES, NETWORK 47 (1005X4)
RB112 1-234-370-21 RES, NETWORK 22 (1005X4)
RB113 1-234-370-21 RES, NETWORK 22 (1005X4)
< VIBRATOR >
X101 1-813-539-11 QUARTZ CRYSTAL UNIT (27 MHz)
************************************************************
DRIVER BOARD
*************
< CAPACITOR >
C715 1-126-933-11 ELECT 100uF 20% 16V
C731 1-126-964-11 ELECT 10uF 20% 50V
C735 1-164-159-11 CERAMIC 0.1uF 50V
C736 1-164-159-11 CERAMIC 0.1uF 50V
C737 1-164-159-11 CERAMIC 0.1uF 50V
C741 1-162-306-11 CERAMIC 0.01uF 20% 16V
C751 1-162-306-11 CERAMIC 0.01uF 20% 16V
C752 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN701 1-784-735-11 CONNECTOR, FFC 13P
CN702 1-784-766-11 CONNECTOR, FFC 5P
* CN703 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN704 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE) 2P
< DIODE >
D701 8-719-947-16 DIODE MTZJ-T-72-5.1A
D711 8-719-983-66 DIODE MTZJ-T-72-3.6B
< IC >
IC701 8-759-598-69 IC BA6956AN
IC712 8-759-598-69 IC BA6956AN
< TRANSISTOR >
Q731 8-729-029-66 TRANSISTOR DTC114ESA
< RESISTOR >
R701 1-249-413-11 CARBON 470 5% 1/4W
R702 1-247-807-31 CARBON 100 5% 1/4W
R711 1-247-831-91 CARBON 1K 5% 1/4W
R712 1-247-847-91 CARBON 4.7K 5% 1/4W
R713 1-247-863-91 CARBON 22K 5% 1/4W
R721 1-247-847-91 CARBON 4.7K 5% 1/4W
R722 1-247-847-91 CARBON 4.7K 5% 1/4W
R723 1-247-847-91 CARBON 4.7K 5% 1/4W
R731 1-247-807-31 CARBON 100 5% 1/4W
R732 1-249-429-11 CARBON 10K 5% 1/4W
R733 1-247-831-91 CARBON 1K 5% 1/4W
Ver. 1.1
