Sony HCD-GN1100D - Electrical Parts List (Continued); JOG, Karaoke, and Main Board (Resistors) Parts

87
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-GN1100D
R1549 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1550 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1557 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1558 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1559 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1560 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1565 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1566 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1567 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1568 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1569 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1570 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1571 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1572 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1573 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1574 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1575 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1576 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1579 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1580 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1581 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1582 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1584 1-216-864-11 SHORT CHIP 0
R1585 1-216-864-11 SHORT CHIP 0
R1586 1-216-864-11 SHORT CHIP 0
R1589 1-216-803-11 METAL CHIP 33 5% 1/10W
R1590 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1591 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1592 1-216-864-11 SHORT CHIP 0
R1594 1-216-836-11 METAL CHIP 18K 5% 1/10W
R1595 1-216-836-11 METAL CHIP 18K 5% 1/10W
R1598 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1600 1-216-838-11 METAL CHIP 27K 5% 1/10W
R1601 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1602 1-216-838-11 METAL CHIP 27K 5% 1/10W
R1603 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1604 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1605 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1606 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1607 1-216-837-11 METAL CHIP 22K 5% 1/10W
************************************************************
A-1226-302-A FUNCTION BOARD, COMPLETE
*************************
< CAPACITOR >
C947 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
CN904 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE) 3P
CN905 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE) 2P
CN950 1-784-747-11 CONNECTOR, FFC 25P
< DIODE >
D904 6-500-809-01 DIODE SELU5223C-STP15 ( ?/1 (LED))
D906 6-500-809-01 DIODE SELU5223C-STP15 (DVD)
D907 6-500-809-01 DIODE SELU5223C-STP15 (TUNER/BAND)
D908 6-500-809-01 DIODE SELU5223C-STP15 (TAPE A/B)
D909 6-500-809-01 DIODE SELU5223C-STP15 (TV/SAT)
D910 6-500-809-01 DIODE SELU5223C-STP15 (VIDEO)
D912 6-500-809-01 DIODE SELU5223C-STP15 (TUNING + / M T )
D913 6-500-809-01 DIODE SELU5223C-STP15 (TUNING –/ t m )
D914 6-500-809-01 DIODE SELU5223C-STP15 ( x )
D915 6-500-809-01 DIODE SELU5223C-STP15 ( X )
D916 6-500-809-01 DIODE SELU5223C-STP15 (REC PAUSE/START)
D918 6-500-809-01 DIODE SELU5223C-STP15 (PRESET +/ > )
D919 6-500-809-01 DIODE SELU5223C-STP15 (PRESET –/ . )
D921 6-501-228-01 DIODE SELU5420E-STP15 ( Y )
D922 6-500-809-01 DIODE SELU5223C-STP15 (ILLUMINATION)
D923 6-500-809-01 DIODE SELU5223C-STP15 (ILLUMINATION)
D924 6-500-809-01 DIODE SELU5223C-STP15 (ILLUMINATION)
D925 6-500-809-01 DIODE SELU5223C-STP15 (ILLUMINATION)
D926 6-500-809-01 DIODE SELU5223C-STP15 (ILLUMINATION)
D927 6-500-809-01 DIODE SELU5223C-STP15 (ILLUMINATION)
D928 8-719-404-50 DIODE MA111-TX
D929 6-500-809-01 DIODE SELU5223C-STP15 (CD SYNC)
D930 6-501-228-01 DIODE SELU5420E-STP15 ( ?/1 (GREEN))
< TRANSISTOR >
Q904 8-729-027-50 TRANSISTOR DTC123JKA-T146
Q905 8-729-027-29 TRANSISTOR DTA123JKA-T146
Q906 8-729-027-50 TRANSISTOR DTC123JKA-T146
Q907 8-729-027-50 TRANSISTOR DTC123JKA-T146
Q908 8-729-027-50 TRANSISTOR DTC123JKA-T146
Q909 8-729-027-50 TRANSISTOR DTC123JKA-T146
Q910 8-729-027-50 TRANSISTOR DTC123JKA-T146
Q911 8-729-027-50 TRANSISTOR DTC123JKA-T146
Q912 8-729-027-50 TRANSISTOR DTC123JKA-T146
Q913 8-729-027-50 TRANSISTOR DTC123JKA-T146
Q914 8-729-027-50 TRANSISTOR DTC123JKA-T146
Q915 8-729-027-50 TRANSISTOR DTC123JKA-T146
Q916 8-729-027-50 TRANSISTOR DTC123JKA-T146
Q921 8-729-027-50 TRANSISTOR DTC123JKA-T146
< RESISTOR >
R900 1-216-814-11 METAL CHIP 270 5% 1/10W
R901 1-216-837-11 METAL CHIP 22K 5% 1/10W
R902 1-216-835-11 METAL CHIP 15K 5% 1/10W
R903 1-216-833-11 METAL CHIP 10K 5% 1/10W
R904 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R905 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R906 1-216-864-11 SHORT CHIP 0
R907 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R908 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R909 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R910 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R911 1-216-821-11 METAL CHIP 1K 5% 1/10W
R912 1-216-819-11 METAL CHIP 680 5% 1/10W
R913 1-216-817-11 METAL CHIP 470 5% 1/10W
R914 1-216-835-11 METAL CHIP 15K 5% 1/10W
R915 1-216-864-11 SHORT CHIP 0
R916 1-216-833-11 METAL CHIP 10K 5% 1/10W
R917 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R918 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R919 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
FUNCTIONEFFECTOR
