Sony HCD-GN1100D - Electrical Parts List (Continued); Motor (LD;TB), PA Board, and Diode Parts

97
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-GN1100D
MOTOR (LD)
MOTOR (TB)
PA
C1176 1-124-589-11 ELECT 47uF 20% 16V
C1177 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1178 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C1190 1-124-589-11 ELECT 47uF 20% 16V
C1191 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1192 1-126-160-11 ELECT 1uF 20% 50V
C1193 1-124-257-00 ELECT 2.2uF 20% 50V
C1194 1-124-589-11 ELECT 47uF 20% 16V
C1195 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN907 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE) 3P
< DIODE >
D1101 8-719-404-50 DIODE MA111-TX
D1102 8-719-404-50 DIODE MA111-TX
D1151 6-501-167-01 DIODE UDZW-TE17-5.1B
D1152 8-719-404-50 DIODE MA111-TX
D1153 8-719-404-50 DIODE MA111-TX
< IC >
IC1100 8-759-710-97 IC NJM4565M-D
IC1101 6-710-879-01 IC R2A15906SP
IC1102 8-759-710-97 IC NJM4565M-D
< JACK >
J1100 1-817-630-11 JACK (LARGE TYPE) (MIC 2)
J1101 1-794-702-11 JACK, HEADPHONE (PHONES)
J1150 1-817-630-11 JACK (LARGE TYPE) (MIC 1)
J1151 1-764-592-11 JACK 3P (VIDEO INPUT)
< JUMPER RESISTOR >
JR1194 1-216-864-11 SHORT CHIP 0
< RESISTOR >
R1100 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1101 1-216-839-11 METAL CHIP 33K 5% 1/10W
R1104 1-216-864-11 SHORT CHIP 0
R1105 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1136 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1137 1-216-809-11 METAL CHIP 100 5% 1/10W
R1138 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1150 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1151 1-216-839-11 METAL CHIP 33K 5% 1/10W
R1154 1-216-864-11 SHORT CHIP 0
R1155 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1156 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1157 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1158 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1159 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1160 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1161 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1163 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1164 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1165 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1166 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1167 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1168 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1169 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1170 1-216-815-11 METAL CHIP 330 5% 1/10W
R1171 1-216-815-11 METAL CHIP 330 5% 1/10W
R1172 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1173 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1174 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1175 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1176 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1177 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1180 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1181 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1182 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1183 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1186 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1187 1-216-809-11 METAL CHIP 100 5% 1/10W
R1188 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1189 1-216-864-11 SHORT CHIP 0
R1190 1-216-864-11 SHORT CHIP 0
R1191 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1192 1-216-815-11 METAL CHIP 330 5% 1/10W
R1193 1-216-815-11 METAL CHIP 330 5% 1/10W
R1194 1-216-864-11 SHORT CHIP 0
R1195 1-216-864-11 SHORT CHIP 0
R1198 1-216-864-11 SHORT CHIP 0
R1199 1-216-864-11 SHORT CHIP 0
< VARIABLE RESISTOR >
RV1100 1-227-452-11 RES, VAR, CARBON 50K (MIC 1 LEVEL)
RV1150 1-227-452-11 RES, VAR, CARBON 50K (MIC 2 LEVEL)
RV1501 1-227-452-11 RES, VAR, CARBON 50K (ECHO LEVEL)
************************************************************
1-687-133-12 MOTOR (LD) BOARD
*****************
************************************************************
1-687-134-12 MOTOR (TB) BOARD
*****************
< CONNECTOR >
CN742 1-784-727-11 CONNECTOR, FFC 5P
************************************************************
A-1231-513-A PA BOARD, COMPLETE
*******************
< CAPACITOR >
C600 1-126-963-11 ELECT 4.7uF 20% 50V
C601 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C602 1-126-923-91 ELECT 220uF 20% 10V
C603 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C604 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C605 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C606 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C608 1-126-965-91 ELECT 22uF 20% 50V
C609 1-128-582-11 ELECT 10uF 20% 100V
C610 1-128-582-11 ELECT 10uF 20% 100V
C616 1-136-495-11 FILM 0.068uF 5% 50V
MIC
