NOTE:
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Color Indication of Appearrance Parts
Example:
KNOB, BALANCE (WHITE) . . . (RED)
↑↑
Parts Color Cabinet's Color
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
• The mechanical parts with no reference num-
ber in the exploded views are not supplied.
• Hardware (# mark) list and accessories are
given in the last of the electrical parts list.
SECTION 7
EXPLODED VIEWS
The components identified by mark
! or dotted line with mark ! are
critical for safety.
Replace only with part number
specified.
• Abbreviation
AED : Northern European model
AUS : Australian
EA3 : Saudi Arabia
EA4 : Israeli
EE : East European
E2 : 120V AC Area in E model
E3 : 240V AC Area in E model
G : German
HK : Hong Kong
IA : Indonesia
(1) CASE, MD ASS'Y SECTION
JE : Tourist
MX : Mexican
MY : Malaysia
SAF : South African
SP : Singapore
TH : Thailand
TW : Taiwan
#1
#1
#1
TCM-220WR2
#2
#2
13
11
12
12
11
5
4
3
2
1
17
18
16
15
14
10
9
8
17
19
