Sony HCD-GR8 - LEAF SWITCH; MAIN

– 108 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< INDUCTOR >
L751 1-410-521-11 INDUCTOR 100uH (GR8: EA3)
< RESISTOR >
R750 1-249-429-11 CARBON 10K 5% 1/4W
R751 1-249-417-11 CARBON 1K 5% 1/4W
R752 1-249-441-11 CARBON 100K 5% 1/4W
R753 1-249-417-11 CARBON 1K 5% 1/4W
R754 1-249-433-11 CARBON 22K 5% 1/4W
R755 1-249-429-11 CARBON 10K 5% 1/4W
R756 1-247-885-00 CARBON 180K 5% 1/4W
R757 1-247-807-31 CARBON 100 5% 1/4W
R758 1-249-433-11 CARBON 22K 5% 1/4W
(GR8: EA3)
R759 1-249-433-11 CARBON 22K 5% 1/4W
(GR8: EA3)
R760 1-249-433-11 CARBON 22K 5% 1/4W
(GR8: EA3)
R761 1-247-881-00 CARBON 120K 5% 1/4W
(GR8: EA3)
R762 1-249-433-11 CARBON 22K 5% 1/4W
(GR8: EA3)
R763 1-249-433-11 CARBON 22K 5% 1/4W
(GR8: EA3)
R764 1-249-433-11 CARBON 22K 5% 1/4W
(GR8: EA3)
R765 1-249-437-11 CARBON 47K 5% 1/4W
(GR8: EA3)
R766 1-249-431-11 CARBON 15K 5% 1/4W
(GR8: EA3)
R767 1-249-431-11 CARBON 15K 5% 1/4W
(GR8: EA3)
< VARIABLE RESISTOR >
RV750 1-223-983-11 RES, VAR, CARBON 50K (MIC LEVEL)
RV751 1-223-983-11 RES, VAR, CARBON 50K (ECHO LEVEL)
(GR8: EA3)
**************************************************************
* 1-650-669-11 LEAF SWITCH BOARD
*****************
< CONNECTOR >
* CN1001 1-568-854-11 SOCKET, CONNECTOR 11P
< TRANSISTOR >
Q1001 8-749-010-90 TRANSISTOR PHOTO REFLECTOR
NJL5165KA-H2
Q1002 8-749-010-90 TRANSISTOR PHOTO REFLECTOR
NJL5165KA-H2
< RESISTOR >
R1001 1-247-818-11 CARBON 300 5% 1/4W
R1002 1-247-820-11 CARBON 360 5% 1/4W
R1003 1-249-414-11 CARBON 560 5% 1/4W
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
< SWITCH >
S1001 1-692-832-11 SWITCH, PUSH (1 KEY) (A PLAY)
S1002 1-692-832-11 SWITCH, PUSH (1 KEY) (B PLAY)
S1004 1-571-281-21 SWITCH, LEAF (A HALF)
S1005 1-571-281-21 SWITCH, LEAF (A CrO2)
S1006 1-572-248-11 SWITCH, LEAF (REC A)
S1007 1-572-248-11 SWITCH, LEAF (B HALF)
S1008 1-571-281-21 SWITCH, LEAF (B CrO2)
S1009 1-571-281-21 SWITCH, LEAF (REC B)
**************************************************************
* A-4398-179-A MAIN BOARD, COMPLETE (GR8: EA3, MY)
* A-4392-820-A MAIN BOARD, COMPLETE (GR8: EA4, TH)
* A-4392-834-A MAIN BOARD, COMPLETE (GR8: SAF)
* A-4392-362-A MAIN BOARD, COMPLETE (GR8: AUS)
* A-4392-361-A MAIN BOARD, COMPLETE (GR8: E2, MX)
* A-4392-360-A MAIN BOARD, COMPLETE
(GR8: E3, HK, IA, SP, TW)
* A-4392-491-A MAIN BOARD, COMPLETE (GR8: JE)
* A-4392-358-A MAIN BOARD, COMPLETE
(RX90: AEP, G, UK, AED)
* A-4392-359-A MAIN BOARD, COMPLETE (RX90: EE, CIS)
*********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C109 1-164-159-11 CERAMIC 0.1uF 50V
C121 1-162-286-31 CERAMIC 220PF 10% 50V
C122 1-162-286-31 CERAMIC 220PF 10% 50V
C123 1-162-306-11 CERAMIC 0.01uF 20% 16V
C131 1-136-495-11 FILM 0.068uF 5% 50V
(RX90)
C132 1-136-495-11 FILM 0.068uF 5% 50V
(RX90)
C133 1-162-294-31 CERAMIC 0.001uF 10% 50V
(RX90)
C171 1-162-286-31 CERAMIC 220PF 10% 50V
C172 1-162-286-31 CERAMIC 220PF 10% 50V
C173 1-162-306-11 CERAMIC 0.01uF 20% 16V
C181 1-136-495-11 FILM 0.068uF 5% 50V
(RX90)
C182 1-136-495-11 FILM 0.068uF 5% 50V
(RX90)
C183 1-162-294-31 CERAMIC 0.001uF 10% 50V
(RX90)
HP/MIC LEAF SWITCH MAIN
