Sony HCD-GR8 - CONNECTOR; DJ

– 106 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
D628 8-719-056-13 DIODE SML79423C-TP15
(DISC IN/PLAY: DISC 2)
D629 8-719-056-13 DIODE SML79423C-TP15
(DISC IN/PLAY: DISC 2)
D630 8-719-056-13 DIODE SML79423C-TP15
(DISC IN/PLAY: DISC 3)
D631 8-719-056-13 DIODE SML79423C-TP15
(DISC IN/PLAY: DISC 3)
D632 8-719-058-03 DIODE SEL5423E-TP15 (·)
D633 8-719-057-97 DIODE SEL5923A-TP15 (∏)
< TRANSISTOR >
Q612 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q613 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q614 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q616 8-729-119-76 TRANSISTOR 2SA1175-HFE
< RESISTOR >
R709 1-249-401-11 CARBON 47 5% 1/4W
R710 1-249-413-11 CARBON 470 5% 1/4W
R711 1-249-409-11 CARBON 220 5% 1/4W
R712 1-249-411-11 CARBON 330 5% 1/4W
R713 1-249-413-11 CARBON 470 5% 1/4W
R714 1-249-415-11 CARBON 680 5% 1/4W
R715 1-249-417-11 CARBON 1K 5% 1/4W
R716 1-249-419-11 CARBON 1.5K 5% 1/4W
R717 1-249-421-11 CARBON 2.2K 5% 1/4W
R718 1-247-804-11 CARBON 75 5% 1/4W
R719 1-247-804-11 CARBON 75 5% 1/4W
R720 1-247-804-11 CARBON 75 5% 1/4W
R721 1-247-804-11 CARBON 75 5% 1/4W
R722 1-247-804-11 CARBON 75 5% 1/4W
R723 1-247-804-11 CARBON 75 5% 1/4W
R724 1-247-807-31 CARBON 100 5% 1/4W
R725 1-247-807-31 CARBON 100 5% 1/4W
R791 1-247-804-11 CARBON 75 5% 1/4W
R792 1-247-804-11 CARBON 75 5% 1/4W
R793 1-247-804-11 CARBON 75 5% 1/4W
R794 1-247-804-11 CARBON 75 5% 1/4W
R795 1-247-804-11 CARBON 75 5% 1/4W
R796 1-247-804-11 CARBON 75 5% 1/4W
< SWITCH >
S645 1-554-303-21 SWITCH, TACTILE (POWER)
S646 1-554-303-21 SWITCH, TACTILE (≠ 0)
S647 1-554-303-21 SWITCH, TACTILE () ±)
S648 1-554-303-21 SWITCH, TACTILE (DISC SKIP EX-CHANGE)
S649 1-554-303-21 SWITCH, TACTILE (DISC 1)
S650 1-554-303-21 SWITCH, TACTILE (DISC 2)
S651 1-554-303-21 SWITCH, TACTILE (DISC 3)
S652 1-554-303-21 SWITCH, TACTILE (p)
S653 1-554-303-21 SWITCH, TACTILE (§ OPEN/CLOSE)
S654 1-554-303-21 SWITCH, TACTILE (· ∏)
*************************************************************
* 1-658-575-11 CONNECTOR BOARD
*****************
< CONNECTOR >
* CN701 1-568-946-11 PIN, CONNECTOR 8P
CN702 1-750-413-11 CONNECTOR, FFC/FPC 8P
< TRANSISTOR >
Q701 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R703 1-249-435-11 CARBON 33K 5% 1/4W
R704 1-249-429-11 CARBON 10K 5% 1/4W
R705 1-249-417-11 CARBON 1K 5% 1/4W
************************************************************
* 1-664-028-11 DECO BOARD
***********
< CONNECTOR >
* CN605 1-568-848-11 SOCKET, CONNECTOR 5P
< DIODE >
D619 8-719-058-04 DIODE SEL5223S-TP15 (RIGHT)
D620 8-719-058-04 DIODE SEL5223S-TP15 (RIGHT)
D621 8-719-058-04 DIODE SEL5223S-TP15 (CENTER)
D622 8-719-058-03 DIODE SEL5423E-TP15 (CENTER)
D623 8-719-058-04 DIODE SEL5223S-TP15 (CENTER)
D624 8-719-058-04 DIODE SEL5223S-TP15 (LEFT)
D625 8-719-058-04 DIODE SEL5223S-TP15 (LEFT)
< TRANSISTOR >
Q610 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q611 8-729-119-76 TRANSISTOR 2SA1175-HFE
< RESISTOR >
R706 1-247-807-31 CARBON 100 5% 1/4W
R707 1-247-807-31 CARBON 100 5% 1/4W
R708 1-247-807-31 CARBON 100 5% 1/4W
R746 1-247-807-31 CARBON 100 5% 1/4W
**************************************************************
* 1-664-088-11 DJ BOARD
*********
< CAPACITOR >
C401 1-164-159-11 CERAMIC 0.1uF 50V
C402 1-126-967-11 ELECT 47uF 20% 10V
CD SW DECOCONNECTOR DJ
